Hints for Cold Weather Operation
If the engine will start, operate the engine until a minimum operating temperature of 80° C (176° F) is achieved. Achieving operating temperature will help prevent the intake valves and exhaust valves from sticking.
The cooling system and the lubrication system for the engine do not lose heat immediately upon shutdown. This means that an engine can be shut down for some time and the engine can still start readily.
Install the correct specification of engine lubricant before the beginning of cold weather.
Check all rubber parts (hoses, fan drive, and belts) weekly.
Check all electrical wiring and connections for any fraying or damaged insulation.
Keep all batteries fully charged and warm.
Fill the fuel tank at the end of each shift.
Drain the water from the fuel system. Refer to this Operation and Maintenance Manual, "Fuel System Primary Filter/Water Separator - Drain" for the correct procedure.
Check the air cleaners and the air intake daily. Check the air intake more often when you operate in snow.
Ensure that the glow plugs are in working order. Refer to Testing and Adjusting Manual, "Glow Plug - Test" for the correct procedure.
Personal injury or property damage can result from alcohol or starting fluids.Alcohol or starting fluids are highly flammable and toxic and if improperly stored could result in injury or property damage.
Do not use aerosol types of starting aids such as ether. Such use could result in an explosion and personal injury.
For jump starting with cables in cold weather, refer to the Operation and Maintenance Manual, "Starting with Jump Start Cables." for instructions.Viscosity of the Engine Lubrication Oil
Correct engine oil viscosity is essential. Oil viscosity affects the amount of torque that is needed to crank the engine. Refer to this Operation and Maintenance Manual, "Fluid Recommendations" for the recommended viscosity of oil.Recommendations for the Coolant
Provide cooling system protection for the lowest expected outside temperature. Refer to this Operation and Maintenance Manual, "Fluid Recommendations" for the recommended coolant mixture.In cold weather, check the coolant often for the correct glycol concentration in order to ensure adequate freeze protection.Engine Block Heaters
Engine block heaters (if equipped) heat the engine jacket water that surrounds the combustion chambers. The block heaters will assist with the following functions:
The ability to start the engine is improved.
Warm up time is reduced.An electric block heater can be activated once the engine is stopped. A block heater can be 110 V or 240 V. The output can be 750/1000 W. Consult your Cat dealer for more information.Idling the Engine
When an engine powered generator set is started in cold weather, the engine rpm speed will be either 1500 rpm or 1800 rpm no load engine speed. The engine powered generator set should not be placed on excess load in order to speed up the warm-up process.While the engine is at either 1500 rpm or 1800 rpm no load, the application of a light load (parasitic load) will assist in achieving the minimum operating temperature. The minimum operating temperature is 80° C (176° F).Recommendations for Coolant Warm Up
Warming up an engine that has cooled below normal operating temperatures due to inactivity. This warming up of an engine should be performed before the engine is returned to full operation. Operation an engine during cold temperature conditions, damage to engine valve mechanisms can result from engine operation for short intervals. Damage to engine valve mechanisms can happen if the engine is started and the engine is stopped many times without being allowed to warm up completely.When the engine is operated below normal operating temperatures, fuel and oil are not burned completely in the combustion chamber. This fuel and oil causes soft carbon deposits to form on the valve stems. Generally, the deposits do not cause problems and the deposits are burned off during operation at normal engine operating temperatures.When the engine is started and the engine is stopped many times without being warm-up completely, the carbon deposits become thicker. The thicker carbon deposits can cause the following problems:
Free operation of the valves is prevented.
Valves become stuck.
Pushrods may become bent.
Other damage to valve train components can result. For this reason, when the engine is started, the engine must be operated until the coolant temperature is 80° C (176° F) minimum. Carbon deposits on the valve stems will be kept at a minimum and the free operation of the valves and the valve components will be maintained.Thoroughly warming up the engine will keep other engine parts in good condition and the service life of the engine will be extended. Lubrication will be improved. There will be less acid and less sludge in the oil. Less acid and less sludge in the oil will provide longer service life for the engine bearings, the piston rings, and other parts. However, limit unnecessary idle time to 10 minutes in order to reduce wear and unnecessary fuel consumption.The Water Temperature Regulator and Insulated Heater Lines
The engine is equipped with a water temperature regulator. When the engine coolant is below the correct operating temperature, jacket water circulates through the engine cylinder block and into the engine cylinder head. The coolant then returns to the cylinder block via an internal passage that bypasses the valve of the coolant temperature regulator. Bypasses the valve of the coolant temperature regulator ensures that coolant flows around the engine under cold operating conditions. The water temperature regulator begins to open when the engine jacket water has reached the correct minimum operating temperature. As the jacket water coolant temperature rises, above the minimum operating temperature the water temperature regulator opens further allowing more coolant through the radiator to dissipate excess heat.The progressive opening of the water temperature regulator operates the progressive closing of the bypass passage between the cylinder block and head. The progressive closing of the bypass passage ensures maximum coolant flow to the radiator in order to achieve maximum heat dissipation.Note: Do not restrict the air flow. Restriction to the air flow can damage the fuel system. Cat strongly discourages the use of all air flow restriction devices such as radiator
