Illustration 1 g06618637Test Step 1. INSPECT ELECTRICAL CONNECTORS AND WIRING
Turn the Engine Control Switch (ECS) to the OFF/RESET position.
Thoroughly inspect all electrical connectors that may be suspect to the ECM. Refer to Troubleshooting, "Electrical Connectors - Inspect" for details.
Check the harness and wiring for abrasion and for pinch points from the engine speed/timing sensors to the ECM.Expected Result:All connectors, pins, and sockets are completely inserted and coupled. The harness and wiring are free of corrosion, of abrasion, and of pinch points.Results:
OK - Proceed to Test Step 2.
Not OK - Repair: Repair the circuit.Verify that the repair eliminates the problem.STOPTest Step 2. CHECK FOR DIAGNOSTIC CODES
Connect the Caterpillar Electronic Technician (ET) to the service tool connector.
Turn the ECS to the ON position.
Look for the following diagnostic codes on Cat ET:
190-02
190-08
342-02
342-08Expected Result:None of the above diagnostic codes are active or recently logged.Results:
OK - The problem seems to be resolved.Repair: If you are troubleshooting an intermittent problem, refer to Troubleshooting, "Electrical Connectors - Inspect".STOP
Not OK - One of the above diagnosticcodes areactive or recently logged. Proceed to Test Step 3.Test Step 3. CHECK THE ENGINE SPEED/TIMING SENSOR
Turn the circuit breaker for the battery to the OFF position.
Turn the ECS to the OFF/RESET position.
Disconnect the suspect sensor.
Inspect the bracket to ensure that the flange of the sensor is flush. Verify that the bracket is not bent.Note: The bracket cannot be replaced separately.
Remove the suspect sensor.
Ensure that the O-ring is installed on the sensor, and ensure that the O-ring is free of damage.
Measure the resistance between terminals 1 and 2 of the suspect sensor. Expected Result:The flange of the sensor is flush. The sensor mounting bracket is not bent. The O-ring is in place. The resistance of the primary sensor is between 75.0 to 230.0 Ohms and the resistance of the secondary sensor is between 600 to 1800 Ohms.Results:
OK - Install the sensor. Verify that the engine speed/timing sensor is seated properly and verify that the bracket is not bent. Do not reconnect the sensor to the engine harness. Proceed to Test Step 4.
Not OK - The engine speed/timing sensor is not seated properly or the bracket is bent. The sensor resistance is out of the acceptable range.Repair: Install a new speed/timing sensor:
Ensure that the O-ring is installed and free of damage.
Ensure that the sensor is properly oriented and that the harness is secured in the proper location.
Seat the sensor and tighten the bolt.
Verify that the repair eliminates the problem. STOPTest Step 4. CHECK FOR A SHORT CIRCUIT IN THE WIRING HARNESSNote: If you are troubleshooting the primary speed/timing sensor, disconnect the J1/P1 ECM connector. If you are troubleshooting the secondary speed/timing sensor, disconnect the J2/P2 ECM connector.Note: As you measure the resistance, pull and/or shake on the wiring harness to check for an intermittent short.
Turn the circuit breaker for the battery to the OFF position.
Turn the ECS to the OFF/RESET position.
Measure the following resistances at the P1 or P2 connector: Primary speed/timing circuit
Measure the resistance between P1:18 and each individual socket on the J2 connector. Then measure the resistance between P1:18 and the engine ground.
Measure the resistance between P1:12 (Primary engine speed/timing sensor -) and each individual socket on the J1 connector. Then measure the resistance between P1:12 and the engine ground .Secondary speed/timing circuit
Measure the resistance between P2:39 (Secondary engine speed/timing +) and each individual socket on the J1 connector. Then measure the resistance between P2:39 and the engine ground.
Measure the resistance between P2:04 (Secondary engine speed timing -) and each individual socket on the J1 connector. Then measure the resistance between P2:04 and the engine ground.Expected Result:The resistance is greater than 20,000 Ohms for each measurement.Results:
OK - The circuit for the suspect sensor is not shorted in the harness. Proceed to Test Step 6.
Not OK - There is a short circuit in the harness.Repair: Repair the circuit.Verify that the repair eliminates the problem.STOPTest Step 5. CHECK FOR AN OPEN CIRCUIT IN THE HARNESS
Fabricate a jumper wire with pins at both ends.
Install the jumper wire into the appropriate ECM connector and then measure the resistance of the circuit. Primary speed/timing circuit
Install the jumper wire to short P1:12 (Primary speed/timing -) and P1:18 (Primary speed/timing +) together.
Measure the resistance between P20:1 (Primary speed/timing -) and P20:2 (Primary speed/timing +).Secondary speed/timing circuit
Install the jumper wire to short P2:04 (Secondary speed/timing -) and P2:39 (Secondary speed/timing +) together.
Measure the resistance between P44:1 (Secondary speed/timing -) and P44:2 (Secondary speed/timing +).
Remove the jumper wire. Expected Result:The resistance is less than 10 Ohms when the jumper wire is installed.Results:
OK - The circuit for the suspect sensor is not open in the harness. The sensor appears to be OK. However, it is possible that there is still a problem with the sensor. Proceed to Test Step 6.
Not OK - There is an open circuit or excessive resistance in the harness or connectors.Repair: Repair the circuit.Verify that the repair eliminates the problem.STOPTest Step 6. TEST THE OPERATION
Reconnect the sensor to the harness and reconnect the harness to the ECM.
Start the engine. Run the engine at normal operating temperature. Expected Result:The engine operates normally.Results:
OK - The engine operates normally. There are no active diagnostic codes for the speed/timing sensor. The initial
