Recommended Actions
Do not crank the engine continuously for more than 30 seconds. Allow the starting motor to cool for two minutes before cranking the engine again.
Machine Faults
Make sure that the Machine Security System (if equipped) is not preventing the engine from starting.
Check for any faults on the machine that could prevent the engine from starting.
If a fault is found on the machine, rectify the fault.
Attempt to start the engine. If the engine will not start, proceed to "Diagnostic Codes". Diagnostic Codes
Connect the electronic service tool to the diagnostic connector.
Check for active diagnostic codes on the electronic service tool.
Troubleshoot any active codes before continuing with this procedure. Refer to Troubleshooting, "Troubleshooting with a Diagnostic Code".
Attempt to start the engine. If the engine will not start, proceed to "Visible Faults". Visible Faults
Visually inspect the engine for the following faults:
Missing components
Damaged components
Damaged electrical cables or loose electrical cables
Oil leaks
Fuel leaks
Check the following items:
Check for smoke from the exhaust when the engine is cranking. If smoke is seen during cranking, there may be a mechanical fault in the engine. Refer to "Low Compression (Cylinder Pressure)".
Check for the proper level of fuel, oil and coolant.
Ensure that the fuel supply valve (if equipped) is in the full OPEN position.
If the ambient temperature is below 0 °C (32 °F), make sure that the correct specification of engine oil and oil for the machine is used.
Check that the battery voltage is correct.
Use the electronic service tool to check the average cranking speed of the engine. If the cranking speed is less than 150 rpm, investigate the cause of the fault.
Make sure that all fuel filters are correctly installed.
Drain any water from the primary fuel filter/water separator.
Rectify any faults that are found during the visual checks.
Attempt to start the engine. If the engine will not start, proceed to "Air Intake and Exhaust System". Air Intake and Exhaust System
Check the air filter restriction indicator, if equipped.
Ensure that the air filter is clean and serviceable.
Check the air intake and exhaust systems for the following defects:
Blockages
Restrictions
Damage to lines or hoses
Repair any defects before attempting to restart the engine.
Attempt to start the engine. If the engine will not start, proceed to "Primary Speed/timing Sensor". Primary Speed/timing Sensor
Disconnect the P401 connector from the primary speed/timing sensor.
Attempt to start the engine.
If the engine starts, check for a fault in the circuit for the primary speed/timing sensor. Refer to Troubleshooting, "Engine Speed/Timing Sensor Circuit - Test".
If the engine does not start, inspect the timing ring on the crankshaft for misalignment.
If necessary, repair the timing ring. Refer to Disassembly and Assembly, "Crankshaft Timing Ring - Remove and Install".
Attempt to start the engine. If the engine will not start, proceed to "Low Pressure Fuel System". Low Pressure Fuel System
If the temperature is below 0 °C (32 °F), check for solidified fuel (wax).
Check for fuel supply lines that are restricted.
Check that the low pressure fuel lines are correctly installed.
Check the diesel fuel for contamination. Refer to Testing and Adjusting, "Fuel Quality - Test".
Check for air in the fuel system. Refer to Testing and Adjusting, "Air in Fuel - Test".
Ensure that the fuel system has been primed. Refer to Testing and Adjusting, "Fuel System - Prime".
Attempt to start the engine. If the engine will not start, continue with this procedure.
Replace the primary fuel filter and the secondary fuel filter. Refer to the Operation and Maintenance Manual, "Fuel System Primary Filter (Water Separator) Element - Replace".
Attempt to start the engine. If the engine will not start, continue with this procedure.
Check the flow of fuel through the transfer pump. If the flow of fuel through the transfer pump is less than 250 mL per minute at 150 rpm, replace the transfer pump. Refer to Disassembly and Assembly, "Fuel Transfer Pump - Remove" and Disassembly and Assembly, "Fuel Transfer Pump - Install".
Attempt to start the engine. If the engine will not start, proceed to "Secondary Speed/timing Sensor". Secondary Speed/timing Sensor
Connect the electronic service tool to the diagnostic connector.
Check that the desired fuel rail pressure is at least 25 MPa (3625 psi) when the engine is cranking.
If the desired fuel rail pressure is less than 25 MPa (3625 psi), perform the following procedure:
Use the electronic service tool to check the signal from the secondary speed/timing sensor while the engine is cranking.
If the signal from the secondary speed/timing sensor is 0 rpm, investigate the secondary speed/timing sensor. Refer to Troubleshooting, "Engine Speed/Timing Sensor Circuit - Test".
If a fault is identified in the circuit for the secondary speed/timing sensor, repair the fault and then attempt to start the engine. If the engine will not start, proceed to "High Pressure Fuel System".
If the signal from the secondary speed/timing sensor is greater than 0 rpm and the engine will not start, proceed to "High Pressure Fuel System". High Pressure Fuel System
Use the electronic service tool to check the absolute fuel rail pressure while the engine is cranking at a minimum speed of 150 rpm.
If the absolute fuel rail pressure is less than 25 MPa (3625 psi), perform the following procedure:
Check that the inlet pressure at the fuel rail pump is greater than 50 kPa (7.25 psi). If the inlet pressure is less than 50 kPa (7.25 psi), repeat the diagnostic process from "Low Pressure Fuel System".
Check for fuel leaks in the high pressure fuel system. Rectify any fuel leaks and then recheck the pressure in the fuel rail. If the fuel rail pressure is greater than 25 MPa (3625 psi), proceed to test step 3.
Use the electronic service tool to perform a solenoid test on the fuel rail pump. Refer to Troubleshooting, "Fuel Rail Pump Solenoid - Test".
If any service has been performed as a result of Step 2.c, attempt to start the engine. If the engine will not start, repeat the diagnostic process from "Machine Faults".
Check the pressure relief valve in the fuel rail for leakage. If the pressure relief valve is leaking, replace the valve and recheck the pressure in the fuel rail.
If the pressure relief valve in the fuel rail is not leaking,
