1. Install the turbocharger on Tool (A).2. Put alignment marks on the two housings and cartridge assembly of the turbocharger for correct alignment during assembly.3. Loosen clamp (3), and remove compressor housing (4) from cartridge assembly (2).4. Loosen the remaining clamp, and remove cartridge assembly (2) from turbine housing (1).
Typical Example5. Put the cartridge group (shown in the illustration) with nut (16) up in Tool (B). Use a 5S9566 Sliding T-Wrench and a universal socket to remove nut (16) that holds the compressor wheel (15) to the wheel assembly (19).6. Remove compressor wheel (15) and housing assembly (6) from wheel assembly (19). Remove piston ring (13) from the wheel assembly.7. Use Tool (C), and remove snap ring (5) from housing assembly (6). Remove insert (14) and sleeve (18) from the housing assembly. Remove seal (22) from insert (14). Remove ring (20) from sleeve (18).8. Remove oil deflector (23), thrust ring (21), bearing assembly (7), spacer sleeve (24) and thrust ring (8) from housing assembly (6).9. Use Tool (D), and remove snap ring (9) from the housing assembly. Remove bearing (25). Remove snap ring (10) with Tool (D).10. Use Tool (D), and remove snap ring (12) from the housing assembly. Remove bearing (26). Remove snap ring (11) with Tool (D).11. Check all the parts of the turbocharger for damage. If any parts are damaged, use new parts for replacement. See Special Instruction Form No. SMHS6854 for turbocharger reconditioning. Also, see Guidelines For Reusable Parts, Form No. SEBF8018. The following steps are for assembly of the turbocharger.12. Make sure that all the oil passages in the turbocharger cartridge housing are clean and free of dirt and foreign material. Do not put oil on any parts of the turbocharger until after the compressor wheel has been installed. After the turbocharger has been assembled, put clean engine oil into the oil inlet of the turbocharger.
Make sure the snap rings that hold bearings (25) and (26) in housing assembly (6) are installed with the round edge of the outside diameter toward the bearing.
13. Install snap ring (11) with Tool (D). Install bearing (26). Install snap ring (12) with Tool (D).14. Install snap ring (10) with Tool (D). Install bearing (25). Install snap ring (9) with Tool (D).15. Put wheel assembly (19) in position on Tool (B) with the threaded portion end up. Put 6V2055 High Vacuum Grease in the groove for piston ring (13) at assembly to one half or more of the depth of the groove all the way around.16. Install piston ring (13) in the groove in wheel assembly (19).17. Put housing assembly (6) in position on wheel assembly (19).18. Install thrust ring (8) and spacer sleeve (24) on wheel assembly (19).19. Make sure the screen is in place in bearing assembly (7). Install bearing assembly (7) over spacer sleeve (24). Make sure the screen in the bearing assembly is facing toward housing assembly (6) when it is installed.20. Install thrust ring (21) and oil deflector (23) on the wheel assembly. Put 6V2055 High Vacuum Grease in the groove of sleeve (18) to one half or more of the depth of the grooves all the way around.21. Install seal (22) on insert (14). Install ring (20) in the groove in sleeve (18). Put sleeve (18) in position in insert (14). Install the insert and sleeve as an assembly on the wheel assembly.22. Use Tool (C), and install snap ring (5) to hold insert (14) in place.23. Install compressor wheel (15) at room temperature as follows:a. Put compressor wheel (15) in position on wheel assembly (19).b. Put a small amount of clean engine oil on the wheel assembly.
Do not put a side force on the shaft when the nut that holds the compressor wheel in position is tightened.
c. Install nut (16) on the wheel assembly. Tighten the nut to a torque of 14 to 17 N m (125 to 150 lb in).d. Remove the nut. Apply 6V1541 Quick Cure Primer on the threads of the wheel assembly.e. Put 9S3265 Retaining Compound on the threads of the wheel assembly and install the nut. Tighten the nut to a torque of 4 N m (40 lb in).f. Tighten the nut an additional 90°.
Typical Example24. Put the cartridge assembly in position in a vise as shown. Make sure softjaws are used. Install Tool (E) on the cartridge assembly to check the end play. End play for a new wheel assembly must be 0.114 0.038 mm (.0045 .0015 in).25. Put turbine housing (1) in position on Tool (A). Put cartridge assembly (2) in position in the housing. Make sure the mark on the cartridge assembly is in alignment with the mark on the turbine housing, and tighten the clamp that fastens cartridge assembly and housing together. Tighten the clamp to a torque of 14 1.1 N m (125 10 lb in). Tap (hit) the clamp lightly all around, and tighten the clamp again to a torque of 14 1.1 N m (125 10 lb in).26. Put compressor housing (4) in position on cartridge assembly (2). Make sure the mark on the compressor housing is in alignment with the mark on the cartridge assembly, and tighten clamp (3) that fastens cartridge assembly and housing together. Tighten the clamp to a torque of 14 1.1 N m (125 10 lb in). Tap (hit) the clamp lightly all around, and tighten the clamp again to a torque of 14 1.1 N m (125 10 lb in).End By:a. install turbocharger
