Table 1
J1939 Code and Description CDL Code and Description Comments
100-1
Engine Oil Pressure : Low - most severe (3) E360 (3)
Low Engine Oil Pressure Oil pressure is lower than the specified pressure for at least 4 seconds. Engine power is reduced. A snapshot is triggered. The code is logged. Factory passwords are required.
After 30 seconds, the ECM will shut down the engine if the "Engine Monitoring Mode" parameter is programmed to "Shut down".
100-17
Engine Oil Pressure : Low - least severe (1) E360 (1)
Low Engine Oil Pressure Oil pressure is below the specified pressure for at least 8 seconds. A snapshot is triggered. The code is logged. Engine performance is not affected.
100-18
Engine Oil Pressure : Low - moderate severity (2) E360 (2)
Low Engine Oil Pressure Oil pressure is lower than the specified pressure for at least 4 seconds. Engine power is reduced. A snapshot is triggered. The code is logged. Factory passwords are required.
After 30 seconds, the Engine Control Module (ECM) will shut down the engine if the "Engine Monitoring Mode" parameter is programmed to "Shut down". Probable Causes
Low engine oil level
Aeration in the oil
Low oil viscosity
Plugged Oil Filter
Faulty oil pump
Faulty engine oil pressure sensor
Faulty bypass valve
Damaged suction tube or cracked suction tube
Excessive wear of engine componentsRecommended Actions
Table 2
Troubleshooting Test Steps Values Results
1. Check the Engine Oil Level
A. Check the engine oil level in the crankcase. Refer to the Operation and Maintenance Manual for calibration of the dipstick gauge.
Note: The oil level can possibly be too far below the oil pump supply tube. The oil pump cannot supply enough lubrication to the engine components.
Engine Oil Level
Result: The engine oil is not low.
Proceed to Test Step 2.
Result: The engine oil level is low.
Repair: Add engine oil to obtain the correct engine oil level. Refer to Operation and Maintenance Manual, "Engine Oil" for the recommendations of engine oil.
1. Start the engine. Inspect the exterior of the engine for oil leaks. Repair any oil leaks.
2. Check for Aerated Oil
A. Sample the engine oil for aeration.
Note: Foamy oil on the dipstick is a good indication of aeration.
Oil Aeration
Result: The oil is not aerated.
Proceed to Test Step 3.
Result: The oil is aerated.
Proceed to Test Step 8.
3. Check the Oil Viscosity
A. Sample the engine oil viscosity. Obtain an S O S Oil Analysis to determine the characteristics of the oil.
B. Access the "Cylinder Cutout Test" in the "Diagnostic Tests" under the "Diagnostics" menu.
C. Perform the "Automatic Cylinder Cutout Test" on Cat ET.
Oil Viscosity
Result: The oil viscosity is correct.
Proceed to Test Step 4.
Result: The oil viscosity is not correct.
Repair: Replace the engine oil. Refer to Operation and Maintenance Manual, "Engine Oil" for the recommendations of engine oil. If the symptom is corrected, return the unit to service.
Proceed to Test Step 4.
4. Replace the Oil Filter
Oil Filter
Result: The oil filter was changed. If the symptom is corrected, return the unit to service.
Proceed to Test Step 5.
5. Check the Oil Pressure Manually
A. Manually check the engine oil pressure. Refer to Systems Operation/Testing and Adjusting, "Engine Oil Pressure - Test" for the correct procedure.
Oil Pressure
Result: The oil pressure meets specifications.
Proceed to Test Step 6.
Result: The oil pressure does not meet specifications.
Repair: Replace the oil pump. If the symptom is corrected, return the unit to service.
Proceed to Test Step 6.
6. Check the Engine Oil Pressure Sensor
A. Remove the connector and the oil pressure sensor.
B. Install an appropriate tee fitting in the pressure sensor port.
C. Install a manual gauge on one side of the tee fitting. Install the oil pressure sensor on the other side of the pipe tee fitting.
D. Start the engine and compare the oil pressure between the manual gauge and Cat ET. The pressure reading must be within 34 kPa ( 5 psi).
Oil Pressure Sensor
Result The pressure is within 34 kPa ( 5 psi).
Proceed to Test Step 7.
Result The pressure is not within 34 kPa ( 5 psi).
Repair: Replace the sensor. If the symptom is corrected, return the unit to service.
Proceed to Test Step 7.
7. Replace the Engine Oil Filter Base
Oil Filter Base
Result: The oil filter base was replaced.
If the symptom is corrected, return the unit to service.
If the symptom still exists, proceed to Test Step 8.
8. Inspect the Oil Pump Suction Tube
A. Remove the oil pan.
B. Inspect the suction tube. Check the joints of the tube for cracks or for a damaged O-ring seal at the connection to the pump.
C. Inspect the inlet screen of the suction tube for a restriction. This restriction will cause cavitation and a loss of engine oil pressure.
Oil Pump Suction Tube
Result: The suction tube and seal are OK.
Proceed to Test Step 9.
Result: The suction tube and seal are not OK.
Repair: Replace any damaged parts.
9. Check for Worn Engine Components
A. Remove the valve covers.
B. Inspect the camshaft and bearings.
C. Remove the oil pan.
D. Excessive clearance at the crankshaft or camshaft bearings will cause low engine oil pressure. Check the engine components for excessive clearance. Also, inspect the piston cooling jets.
Worn Parts
Result: There are worn engine components.
Repair: Replace parts, if necessary. Check the Reuse and Salvage Guidelines for the reusability of existing engine components.
If the procedure did not correct the issue, contact your Cat dealer Technical Communicator (TC). For further assistance, your TC can confer with the Dealer Solutions Network (DSN).
