Table 1
Specifications for 360-9660 Clean Emissions Module Ar and 370-9526 Clean Emissions Module Ar
Callout     Part Number     Part Name     Specification Description
2     -     Nuts     Torque to...................
17 N m (151 lb in)
8     359-5885     Clamp     Torque to...................
35 N m (26 lb ft)
13     -     Bolts     Torque to...................
55 N m (41 lb ft)
19     -     Nuts     Torque to...................
22 N m (195 lb in)    Removal Procedure
Wear goggles, gloves, protective clothing, and a National Institute for Occupational Safety and Health (NIOSH) approved P95 or N95 half-face respirator when handling a used Diesel Particulate Filter or Catalytic Converter Muffler. Failure to do so could result in personal injury.
The muffler, catalytic converter/muffler, and diesel particulate filter will become extremely hot during engine operation. A hot muffler, catalytic converter/muffler and diesel particulate filter can cause serious burns. Allow adequate cooling time before working on or near the muffler, catalytic converter/muffler and diesel particulate filter.
Do not strike any part of the assembly of the Diesel Particulate Filter (DPF). Do not allow any object to contact the internal element of the DPF. If the internal element of the DPF becomes damaged, the assembly must be replaced.
Illustration 1 g02520776
Illustration 2 g02496917
Illustration 3 g02496977
If necessary, remove the Original Equipment Manufacturer's (OEM) exhaust tube assembly from outlet (3) .
Disconnect the flexible exhaust pipe assembly (9) from inlet (10). Refer to Disassembly and Assembly, "Flexible Exhaust Pipe" for the correct procedure.
Make a temporary mark (5) in order to show the direction of the exhaust gases.
Make temporary alignment marks in Positions (A), Position (B), Positions (C) and Position (D) in order to identify the correct position of clamps (2) and DPF (6) .
Using a fixed position that is easily accessible, measure Dimension (E) from the DPF mounting bracket to the end of the DPF. Record Dimension (E) for installation purposes.
Using a fixed position that is easily accessible on the application, measure to the center of the DPF outlet (3). Record Dimension (F) for installation purposes.
Remove the temperature sensor. Refer to Disassembly and Assembly, "Temperature Sensor (DPF)" for the correct procedure.
Disconnect the wiring harness from soot antenna (4) and soot antenna (7) .
Remove the soot antenna's. Refer to Disassembly and Assembly, "Soot Antenna" for the correct procedure.
Remove the nuts from clamps (2). Position the clamps away from the DPF in order to allow removal of the DPF.
Attach a suitable lifting device to the DPF. The weight of the DPF is approximately 43 kg (95 lb).
Use the suitable lifting device in order to remove the DPF from the bracket for the clean emission module.
Illustration 4 g02464317
Illustration 5 g02464396
If necessary, follow Step 13.a thought Step 13.f in order to remove bracket (11) from valve mechanism cover (20) .
Cut cable straps (12) from the harness assembly for the temperature sensor.
Slide locking tab (15) into the unlock position. Disconnect harness assembly (18) .
Slide locking tab (16) into the unlock position. Disconnect harness assembly (17) .
Remove bolts (13) and position bracket (14) away from bracket (11) .
Remove nuts (19) from bracket (11) .
Remove bracket (11) from valve mechanism cover (20) .
