Fuel leaked or spilled onto hot surfaces or electrical components can cause a fire. To help prevent possible injury, turn the start switch off when changing fuel filters or water separator elements. Clean up fuel spills immediately.
Note: Refer to Testing and Adjusting Manual , "Cleanliness of Fuel System Components" for detailed information on the standards of cleanliness that must be observed during ALL work on the fuel system.
Ensure that the engine is stopped before any servicing or repair is performed.
Note: This fuel filter can be identified by the six drain holes in the filter. Refer to illustration 1.
Illustration 1 g01430615After the engine has stopped, you must wait for 60 seconds in order to allow the fuel pressure to be purged from the high pressure fuel lines before any service or repair is performed on the engine fuel lines. If necessary, perform minor adjustments. Repair any leaks from the low pressure fuel system and from the cooling, lubrication or air systems. Replace any high pressure fuel line that has leaked. Refer to Disassembly and assembly Manual, "Fuel Injection Lines - Install".
Do not allow dirt to enter the fuel system. Thoroughly clean the area around a fuel system component that will be disconnected. Fit a suitable cover over disconnected fuel system component.
Ensure that the fuel supply valve (if equipped) is in the OFF position. Place a suitable container under the fuel filter in order to catch any fuel that might spill. Clean up any spilled fuel.
Illustration 2 g01430609
Typical example
Clean the outside of the fuel filter. Use 1U-8760 Chain Wrench in order to remove the canister (1) from the engine and dispose of the canister in a safe place.
Ensure that dirt can not enter the new canister. Do not fill the canister with fuel before the canister is installed. Lubricate the O ring seal (1) with clean engine oil on the new canister.
Install the new canister. Do not use a tool in order to install the canister. Tighten the canister by hand.
Spin on the canister until the O ring seal contacts the sealing surface. The canister will require a ¾ of a full turn in order to tighten the canister correctly.
Prime the fuel system. Refer to the Operation and Maintenance Manual, "Fuel System - Prime" for more information. Type Two
Fuel leaked or spilled onto hot surfaces or electrical components can cause a fire. To help prevent possible injury, turn the start switch off when changing fuel filters or water separator elements. Clean up fuel spills immediately.
Note: Refer to Testing and Adjusting Manual , "Cleanliness of Fuel System Components" for detailed information on the standards of cleanliness that must be observed during ALL work on the fuel system.
Ensure that the engine is stopped before any servicing or repair is performed.
Illustration 3 g01430619This fuel filter can be identified by the 12 drain holes in the filter. Refer to illustration 3.After the engine has stopped, you must wait for 60 seconds in order to allow the fuel pressure to be purged from the high pressure fuel lines before any service or repair is performed on the engine fuel lines. If necessary, perform minor adjustments. Repair any leaks from the low pressure fuel system and from the cooling, lubrication or air systems. Replace any high pressure fuel line that has leaked. Refer to Disassembly and Assembly Manual, "Fuel Injection Lines - Install".
Ensure that the fuel supply valve (if equipped) is in the OFF position. Place a suitable container under the fuel filter in order to catch any fuel that might spill. Clean up any spilled fuel.
Illustration 4 g01430620
Typical example
Clean the outside of the fuel filter. Use 1U-8760 Chain Wrench in order to remove the canister (2) from the engine and dispose of the canister in a safe place.
Ensure that dirt can not enter the new canister. Do not fill the canister with fuel before the canister is installed. Lubricate the O ring seal (1) with clean engine oil on the new canister.
Install the new canister. Do not use a tool in order to install the canister. Tighten the canister by hand.
Spin on the canister until the O ring seal contacts the sealing surface. Then rotate the canister 360 degree in order to tighten the canister correctly.
Remove the container and dispose of the fuel in a safe place. If equipped, open the fuel supply valve.
Prime the fuel system. Refer to the Operation and Maintenance Manual, "Fuel System - Prime" for more information.
