Introduction
This Special Instruction is intended to provide information on the Engine Overhaul Kit Consist and detailed information on specific parts that should be used based on engine arrangements.This Engine Overhaul Kit may contain extra parts and extra quantities due to the variety of engine arrangements assigned to a given kit. Refer to the corresponding Parts Manual or Disassembly and Assembly manual in Table 1.Note: This Kit may contain upgraded parts. These upgraded part numbers may be different than what you have in the parts manual or engine, but these parts have been technically reviewed for compatibility with your application. Note: This kit contains Sub-Kits and includes additional parts needed to perform an engine rebuild.Note: This kit contains a set of six standard rod bearings.Note: This kit does not contain main bearings and thrust plates.Note: For assistance with technical questions, contact your local Cat dealer. Note: For more information on other kits that are available, visit www.catrebuildkits.com.Reference Material
Table 1
Machine     Engine Arrangement     Machine Serial Number Prefix     Engine Serial Number Prefix     Parts Book Media     Disassembly and Assembly Media
966G II     223-1553     S/N:AWZ
S/N:AXL     S/N:3PD     XEBP8503     SENR9537
223-1556 S/N:ANT
S/N:ANZ     S/N:3PD     SEBP3487
180-3191
220-0794
223-1553 S/N:AWY
S/N:AXJ     S/N:3PD     SEBP3277     415-8631 Bronze Overhaul Kit Consist
Table 2
415-8631 Bronze Overhaul Kit Consist
Sub-Kits
Part Number     Part Name     Qty
224-5797     Single Fuel Injector Gasket Kit     6
315-6714     Water Pump Installation Gasket Kit     1
415-8630     Oil Cooler Lines Gasket Kit     1
363-6420     Rear Structure Gasket Kit     1
418-4757     Central and Lower Structure Gasket Kit     1
415-8664     Turbocharger Installation Gasket Kit     1
417-7911     Front Structure Gasket Kit     1
319-0847     Single Cylinder Head Gasket Kit     1
Additional Parts Included in This Kit
Part Number     Part Name     Qty
1P-0436     Gasket     1
1R-0762     Fuel Filter     1
1R-1808     Engine Oil Filter     1
3E-8017     Locknut     12
3J-1907     O-Ring Seal     1
3J-7354     O-Ring Seal     1
4F-5695     Cup Plug     6
4P-4369     Spacer     12
4W-4011     Temperature Regulator     2
5P-3456     O-Ring Seal     6
6V-0852     Dust Cap     1
6V-4367     O-Ring Seal     2
6V-4589     O-Ring Seal     1
6V-5839     Washer     12
6V-6609     O-Ring Seal     1
6V-6923     Backup Ring     1
6V-8676     O-Ring Seal     1
8L-2786     O-Ring Seal     1
8T-4984     Hose Clamp     2
8T-5452     O-Ring Seal     1
9Y-4357     Breather As     1
033-6033     O-Ring Seal     1
061-9455     O-Ring Seal     1
116-3715     Taperlock Stud     12
131-6645     Hose     1
175-0454     Bolt     26
190-7634     O-Ring Seal     6
214-7568     O-Ring Seal     3
216-5583     Bushing     5
216-5584     Bushing     1
216-5585     Bushing     1
217-0577     Connecting Rod Bearing     6
217-3673     Isolation Seal     Table 8
217-3674     Fasteners
