Table 1
J1939 Code and Description CDL Code and Description Comments
5246-0
Aftertreatment SCR Operator Inducement Severity : High - most severe (3) E1389 (3)
Aftertreatment #1 SCR Operator Inducement This code is a Level 3 inducement associated with an emissions system fault. The engine is derated 100%, limited to low idle or 1000 RPM, and can experience 5 minute rolling shutdowns.
5246-15
Aftertreatment SCR Operator Inducement Severity : High - least severe (1) E1389 (1)
Aftertreatment #1 SCR Operator Inducement This code is a Level 1 inducement associated with an emissions system fault.
5246-16
Aftertreatment SCR Operator Inducement Severity : High - moderate severity (2) E1389 (2)
Aftertreatment #1 SCR Operator Inducement This code is a Level 2 inducement associated with an emissions system fault. Refer to Systems Operation, "DEF Dosing Control System" for details on inducement configuration options and inducement actions.Associated Codes
Table 2
Associated Codes
J1939 Code and Description CDL Code and Description Inducement Category
1231-9
J1939 Network #2 : Abnormal Update Rate 2348-9
SAE J1939 Data Link #2 : Abnormal Update Rate Category 1
1231-14
J1939 Network #2 : Special Instruction 2348-14
SAE J1939 Data Link #2 : Special Instruction Category 2
1235-9
J1939 Network #3 : Abnormal Update Rate 5856-9
SAE J1939 Data Link #3 : Abnormal Update Rate Category 1
1235-14
J1939 Network #3 : Special Instruction 5856-14
SAE J1939 Data Link #3 : Special Instruction Category 2
1761-3
Aftertreatment #1 DEF Tank Volume #1 : Voltage Above Normal 3130-3
Aftertreatment #1 DEF Tank #1 Level Sensor : Voltage Above Normal Category 1
1761-4
Aftertreatment #1 DEF Tank Volume #1 : Voltage Below Normal 3130-4
Aftertreatment #1 DEF Tank #1 Level Sensor : Voltage Below Normal Category 1
2659-17
EGR Mass Flow Rate : Low - least severe (1) E1095 (1)
Low EGR Mass Flow Rate Category 3
2791-5
EGR Valve Control : Current Below Normal 3405-5
EGR Valve Control : Current Below Normal Category 3
3031-7
Aftertreatment #1 DEF Tank Temperature : Not Responding Properly E1441 (2)
Aftertreatment #1 DEF Tank Temperature #1 Not Responding Category 1
3031-16
Aftertreatment #1 DEF Tank Temperature : High - moderate severity (2) E960 (2)
High Aftertreatment #1 DEF Tank Temperature #1 Category 2
3031-18
Aftertreatment #1 DEF Tank Temperature : Low - moderate severity (2) E1398 (2)
Low Aftertreatment #1 DEF Tank Temperature #1 Category 2
3216-7
Aftertreatment #1 Intake NOx : Not Responding Properly E1431 (2)
Invalid Aftertreatment #1 Intake NOx Level #1 Category 2
3216-11
Aftertreatment #1 Intake NOx : Other Failure Mode 3655-11
Aftertreatment #1 Intake NOx Level Sensor : Other Failure Mode Category 2
3216-12
Aftertreatment #1 Intake NOx : Failure 3655-12
Aftertreatment #1 Intake NOx Level Sensor : Failure Category 2
3217-16
Aftertreatment #1 Intake O2 : High - moderate severity (2) E1407 (2)
High Aftertreatment #1 Intake O2 Concentration #1 Category 1
3226-7
Aftertreatment #1 Outlet NOx : Not Responding Properly E1432 (2)
Invalid Aftertreatment #1 Outlet NOx Level #1 Category 3
3226-11
Aftertreatment #1 Outlet NOx : Other Failure Mode 3609-11
Aftertreatment #1 Outlet #1 NOx Level Sensor : Other Failure Mode Category 3
3226-12
Aftertreatment #1 Outlet NOx : Failure 3609-12
Aftertreatment #1 Outlet #1 NOx Level Sensor : Failure Category 3
3227-16
Aftertreatment #1 Outlet O2 : High - moderate severity (2) E1408 (2)
High Aftertreatment #1 Outlet O2 Concentration #1 Category 1
3360-3
Aftertreatment #1 DEF Controller : Voltage Above Normal 3820-3
Aftertreatment #1 DEF Controller #1 : Voltage Above Normal Category 1
3360-4
Aftertreatment #1 DEF Controller : Voltage Below Normal 3820-4
Aftertreatment #1 DEF Controller #1 : Voltage Below Normal Category 1
3360-9
Aftertreatment #1 DEF Controller : Abnormal Update Rate 3820-9
Aftertreatment #1 DEF Controller #1 : Abnormal Update Rate Category 2
3360-12
Aftertreatment #1 DEF Controller : Failure 3820-12
Aftertreatment #1 DEF Controller #1 : Failure Category 2
3361-5
Aftertreatment #1 DEF Dosing Unit : Current Below Normal 3821-5
Aftertreatment #1 DEF Dosing Valve Actuator #1 : Current Below Normal Category 2
3361-6
Aftertreatment #1 DEF Dosing Unit : Current Above Normal 3821-6
Aftertreatment #1 DEF Dosing Valve Actuator #1 : Current Above Normal Category 2
3361-7
Aftertreatment #1 DEF Dosing Unit : Not Responding Properly 3821-7
Aftertreatment #1 DEF Dosing Valve Actuator #1 : Not Responding Properly Category 1
3361-11
Aftertreatment #1 DEF Dosing Unit : Other Failure Mode 3821-11
Aftertreatment #1 DEF Dosing Valve Actuator #1 : Other Failure Mode Category 1
3361-14
Aftertreatment #1 DEF Dosing Unit : Special Instruction 3821-14
Aftertreatment #1 DEF Dosing Valve Actuator #1 : Special Instruction Category 1
3511-11
Sensor Supply Voltage 3 : Other Failure Mode 3482-11
Sensor Supply #3 : Other Failure Mode C
