Type 1
Table 1
Required Tools
Tool Part Number Part Description Qty
A 5P-1733 Seal Locator 1
B 5P-1737 Bolts 3
C 9S-8858 Nut (Seal Installer) 1
D 6V-6142 Front Seal Installer 1
Keep all parts clean from contaminants.Contaminants may cause rapid wear and shortened component life.
Note: The front seal and the wear sleeve must be replaced at the same time. Once the seal and the wear sleeve are separated, these components cannot be used again. Refer to Special Instruction, SMHS8508, "Special Handling Information and Installation Instructions for Crankshaft Seal Groups That Have Hydrodynamic Grooves In the Sealing Lip" before the seal is serviced. Note: Do not use any type of lubricant during the installation of the crankshaft seal and the wear sleeve.
Before installation of the crankshaft seal and the wear sleeve, inspect the crankshaft for scratches. Also, inspect the crankshaft for any distortion on the surface that may lead to an out of round condition. Use a polishing cloth in order to remove any imperfections on the crankshaft.
Use 4C-9500 Quick Cure Primer to clean the outside diameter of the crankshaft and the inside diameter of wear sleeve (1).
Apply 4C-9507 Retaining Compound to the outside diameter of the crankshaft. Apply 4C-9507 Retaining Compound to the inside diameter of wear sleeve (1).
Illustration 1 g00829187
Type 1 seal design.
(1) Seal
(2) Wear sleeve
Illustration 2 g00829675
Typical example
Fasten Tool (A) to the crankshaft with Tool (B).
The front and rear seals and wear sleeves have different spiral grooves in the seal. Because of this type of design, the front seal group for an engine is different from the rear seal group. If a seal group is installed on the wrong end of the engine, oil can actually be taken out of the engine instead of moving oil back into the engine.
Illustration 3 g00515623Note: Install the seal with the arrow that shows the direction of crankshaft rotation toward the front of the engine.
Position wear sleeve (2) and seal (1) on Tool (A). Install Tool (D) on Tool (A). Lubricate the face of the washer on Tool (C). Install Tool (C) on Tool (A).
Tighten Tool (C) until Tool (D) contacts Tool (A).
Remove Tools (A), (B), (C), and (D). Check the crankshaft seal and the wear sleeve for the correct installation. Type 2
Table 2
Required Tools
Tool Part Number Part Description Qty
A 5P-1733 Seal Locator 1
B 5P-1737 Bolts 3
C 9S-8858 Nut (Seal Installer) 1
D 6V-6142 Front Seal Installer 1
Keep all parts clean from contaminants.Contaminants may cause rapid wear and shortened component life.
Note: The front seal and the wear sleeve must be replaced at the same time. Once the seal and the wear sleeve are separated, these components cannot be used again. Refer to Special Instruction, SMHS8508, "Special Handling Information and Installation Instructions for Crankshaft Seal Groups That Have Hydrodynamic Grooves In the Sealing Lip" before the seal is serviced. Note: Do not use any type of lubricant during the installation of the crankshaft seal and the wear sleeve.
Before installation of the crankshaft seal and the wear sleeve, inspect the crankshaft for scratches. Also, inspect the crankshaft for any distortion on the surface that may lead to an out of round condition. Use a polishing cloth in order to remove any imperfections on the crankshaft.
Use 4C-9500 Quick Cure Primer to clean the outside diameter of the crankshaft. Note: The type 2 seal comes with the 4C-9507 Retaining Compound that is already applied to the inside diameter of the wear sleeve.
Illustration 4 g00829143
Type 2 seal design.
(1) Seal
(2) Wear sleeve flange
(3) Wear sleeve
