06115-ZZ3-000 Honda GASKET KIT (BF60)

(11) Install dowel to a dimension of ... 16.8 0.5 mm (0.66 0.02 in)(12) Distance from top surface of housing to top of lower governor drive bearing ... 28.4 0.5 mm (1.12 .02 in)(13) Position the top governor drive bearing (notch end up) with the notch in alignment with the center of oil hole (Z). A line drawn through the center of the notch and hole (Z) should make an angle (U) of 10 5 degrees with centerline (W) as shown. Install the bearing even with the top surface of the housing ... +0.00 to -0.15 mm (+.000 to -.006 in)(14) Install dowel to get a dimension from centerline of fuel injection pump bore to dowel (seal dowel hole with aluminum ball) ... 14.76 0.10 mm (.581 .004 in)(15) Distance from end of plug to face of housing ... 1.25 0.25 mm (.049 .010 in)(16) End of plug to be even with outside face of housing.(17) Install pins until they contact bottom of housing casting.3412C
(1) Install pin to get a dimension of ... 4.78 0.25 mm (.188 .010 in)(2) Install dowel to get a dimension of ... 12.19 0.25 mm (.480 .010 in)(3) Rack bearing alignment. The center of the rack bearing tab must be within 0.05 mm (.002 in) of a vertical line that: (a) goes through the center of the rack bearing(b) is parallel to the vertical centerline of injection pump housing The following tooling is available to position the rack bearings correctly: 5P6217 Fixture and 5P6218 Driver.The correct bearing depth [19.1 0.5 mm (.75 .02 in)] is controlled when driver is stopped by fixture.(4) Position of camshaft bearing joints (X) must be limited to area (A) ... 30 1 degree When viewed from the Front of the injection pump housing, all three camshaft bearings must be installed with the bearing joint (X) in an area (A) between a vertical position and a position 30 degrees to the Right of vertical. At the same time, oil hole (Y) in the two end bearings (center bearing has no oil hole) must be to the Left of vertical.(5) Install dowels to get a dimension of ... 9.7 0.5 mm (.38 .02 in)(6) Distance from bottom of housing to end of rear hollow dowel ... 1.5 0.3 mm (.06 .01 in)(7) Maximum distance from bottom of housing to end of front hollow dowel ... 1.0 mm (.04 in)(8) Torque for bolts ... 55 7 N m (40 5 lb ft)(9) Distance from rear bearing bore face to installed rear camshaft bearing ... 4.8 0.5 mm (.19 .02 in)(10) Distance from rear bearing bore face to installed center camshaft bearing ... 127.0 0.5 mm (5.00 .02 in)(11) Distance from front bearing bore face to installed front camshaft bearing ... 1.0 0.5 mm (.04 .02 in)(12) Install plug to a depth of ... 1.3 0.5 mm (.05 .02 in)(13) Pressure oil passage.(14) Install pins until they contact bottom of housing casting. (15) Distance from top surface of housing to top of lower governor drive bearing ... 28.4 0.5 mm (1.12 .02 in)(16) Position the top governor drive bearing (notch end up) with the notch in alignment with the center of oil hole (Z). A line drawn through the center of the notch and hole (Z) should make an angle (U) of 10 5 degrees with centerline (W) as shown. Install the bearing even with the top surface of the housing ... +0.00 to -0.15 mm (+.000 to -.006 in)(17) Install dowel to get a dimension from centerline of fuel injection pump bore to dowel (seal dowel holes with aluminum ball) ... 14.76 0.10 mm (.581 .004 in)(18) Distance from end of plug to face of housing ... 1.25 0.25 mm (.049 .010 in)
