06323-ZW1-V02 Honda PANEL KIT, SWITCH (SINGLE) (Honda Code 7225402).


06323-ZW1-V02 PANEL KIT, SWITCH (SINGLE) (Honda Code 7225402). Honda BF90A2 JRTA, BF90A2 LRTA, BF90A2 XRTA PANEL
06323-ZW1-V02 PANEL KIT, SWITCH (SINGLE) (Honda Code 7225402). Honda
Rating:
98

Buy PANEL KIT, SWITCH (SINGLE) (Honda Code 7225402). 06323-ZW1-V02 Honda genuine, new aftermarket parts with delivery
Number on catalog scheme: 1


Compatible models:

Honda entire parts catalog list:

BF90A2 JRTA 2002
BF90A2 LRTA 2002
BF90A2 XRTA 2002

Information:


Table 1
Code and Description Conditions which Generate this Code System Response
827-8 Left Exhaust Temperature Sensor abnormal frequency, pulse width, or period The Electronic Control Module (ECM) detects a sensor frequency that is greater than 600 Hz or less than 400 Hz.
The ECM detects a duty cycle that is greater than 88 percent or a duty cycle that is less than 22 percent. The ECM flags the exhaust temperature as invalid data.
828-8 Right Exhaust Temperature Sensor abnormal frequency, pulse width, or period System OperationA Pulse Width Modulated Sensor (PWM) provides a signal to the Electronic Control Module (ECM) from the exhaust temperature sensor. The sensor receives a 8.0 0.4 VDC regulated voltage from the ECM.The sensor generates a PWM signal that is in a specific range of duty cycle that is sent to the ECM. This range is directly related to the temperature that is sampled by the temperature probe. When the temperature of the sensor probe is 50 °C (122 °F) the duty cycle output of the sensor is 22 percent. When the temperature of the sensor probe is 850 °C (1550 °F) the duty cycle output of the sensor is 88 percent. As the temperature of the probe fluctuates between the minimum and the maximum temperatures, the duty cycle fluctuates on a scale that is directly related to the temperature of the temperature probe.The ECM performs an automatic calibration of this sensor whenever the ECM is powered and the engine has been off for at least five seconds.The ECM provides short circuit protection for the internal power supply. A short circuit to the battery will not damage the internal power supply of the ECM.
Illustration 1 g01380486
Schematic of the sensor circuit for the PWM sensors
Table 2
Troubleshooting Test Steps Values Results
1. Verify that the "Exhaust Temperature Sensor Installation Status" Parameter is Programmed Correctly
A. Remove electrical power from the ECM.
B. Connect the Cat Electronic Technician (ET) to the service tool connector.
C. Restore electrical power to the ECM.
D. Establish communication with the ECM.
E. Verify that the "Exhaust Temperature Sensor Installation Status" parameter is programmed to "Installed".
F. Remove electrical power from the ECM.
Parameters
Result: The "Exhaust Temperature Sensor Installation Status" parameter is programmed correctly. Proceed to Test Step 2.
Result: The "Exhaust Temperature Sensor Installation Status" parameter is not programmed correctly.
Repair: Program the "Exhaust Temperature Sensor Installation Status" parameter to "Installed". Verify that the repair eliminates the problem.
STOP
2. Inspect the Electrical Connectors and the Wiring
A. Thoroughly inspect connectors. Refer to Troubleshooting, "Electrical Connectors - Inspect", for details that are related to inspection of the electrical connectors.
B. Perform a 45 N (10 lb) pull test on each of the wires in the ECM connector and the customer connector that are associated with the circuit.
C. Check the allen head screw on each ECM connector for the proper torque. refer to Troubleshooting, "Electrical Connectors - Inspect", for the correct torque values.
D. Check the harness and the wiring for abrasion and for pinch points.
Connectors, pins, and sockets
Result: The connectors and wiring appear to be OK. Proceed to Test Step 3.
Result: The connectors and/or wiring are not OK.
Repair: Repair the connectors or wiring and/or replace the connectors or wiring.
STOP
3. Check the Supply Voltage at the Sensor
A. Disconnect the exhaust temperature sensor at the harness connector.
B. Restore electrical power to the ECM. Turn the keyswitch to the ON position.
C. Measure the voltage across terminal A (digital sensor supply) and terminal B (digital return) on the harness side of the connector.
D. Remove electrical power from the ECM. Turn the keyswitch to the OFF position.
E. Restore the wiring to the original configuration.
The supply voltage measures 8.0 0.4 VDC at the sensor connector.
Result: The correct supply voltage is measured at the sensor connector. The sensor is receiving the correct supply voltage. Proceed to Test Step 4.
Result: The voltage is not correct at the sensor connector.
Repair: There is a problem in the circuit for the digital sensor supply that is between the ECM and the exhaust temperature sensor. Repair the circuit. Refer to Troubleshooting, "Sensor Supply - Test", for details that are related to troubleshooting a problem with the circuit.
STOP
4. Check the Signal Frequency and the Duty Cycle at the Sensor
A. Disconnect the sensor connector from the exhaust temperature sensor.
B. Remove the signal wire from terminal C of the harness side of the connector for the exhaust temperature sensor.
C. Install a 7X-6370 Adapter Cable As (3-PIN BREAKOUT) at the sensor connector.
D. Connect the sensor to the breakout harness.
E. Restore electrical power to the ECM. Turn the keyswitch to the ON position.
F. Measure the frequency and the duty cycle between terminal B (digital return) and terminal C (exhaust temperature) at the 7X-6370 Adapter Cable As (3-PIN BREAKOUT).
G. Remove electrical power from the ECM. Turn the keyswitch to the OFF position.
H. Remove the breakout harness. Restore the wiring to the original configuration.
The frequency is between 400 and 600 Hz. The duty cycle is between 22 and 88 percent.
Note: When the temperature of the sensor probe is 50 °C (122 °F) the duty cycle output of the sensor is 22 percent. When the temperature of the sensor probe is 850 °C (1550 °F) the duty cycle output of the sensor is 88 percent.
Result: The frequency and the duty cycle are within specifications. The sensor is producing a valid signal. Proceed to Test Step 5.
Result: The frequency and the duty cycle are not within specifications.
Repair: The sensor is not producing a valid signal. Replace the exhaust temperature sensor. Verify that the repair eliminates the problem.
STOP
5. Check the Signal Frequency and the Duty Cycle at the ECM
A. Remove the signal wire of the suspect sensor from the P2 ECM connector to isolate the circuit. The wire will be P2-39 for the right sensor and P2-65 for the left sensor.
B. Restore electrical power to the ECM. Turn the keyswitch to the ON position.
C. Install a 7X-1709 Multimeter Probe (BLACK) into terminal location P2-14 (digital return) at the ECM connector.
Note: Ensure that the multimeter probe is in good repair. A bent probe may contact other terminals inside


Parts panel Honda:

32340-ZW1-V03

32340-ZW1-V03 PANEL ASSY., CONTROL (Honda Code 7225956).
BF75A1 LRTA, BF75A1 XRTA, BF75A2 LRTA, BF75A2 XRTA, BF75A3 LRTA, BF75A3 XRTA, BF75A4 LRTA, BF75A4 XRTA, BF75AT LRTA, BF75AT XRTA, BF75AW LRTA, BF75AW XRTA, BF75AX LRTA, BF75AX XRTA, BF75AY LRTA, BF75AY XRTA, BF90A1 JRTA, BF90A1 LRTA, BF90A1 XRTA, BF9
32340-ZW1-V02

32340-ZW1-V02 PANEL ASSY., CONTROL (Honda Code 6148118).
BF75A1 LRTA, BF75A1 XRTA, BF75A2 LRTA, BF75A2 XRTA, BF75AT LRTA, BF75AT XRTA, BF75AW LRTA, BF75AW XRTA, BF75AX LRTA, BF75AX XRTA, BF75AY LRTA, BF75AY XRTA, BF90A1 JRTA, BF90A1 LRTA, BF90A1 XRTA, BF90A2 JRTA, BF90A2 LRTA, BF90A2 XRTA, BF90A4 JRTA, BF9
06323-ZW1-V13

06323-ZW1-V13 PANEL KIT, SWITCH (DUAL) (Honda Code 7225436).
BF75A1 LRTA, BF75A1 XRTA, BF75A2 LRTA, BF75A2 XRTA, BF75A3 LRTA, BF75A3 XRTA, BF75A4 LRTA, BF75A4 XRTA, BF75AT LRTA, BF75AT XRTA, BF75AW LRTA, BF75AW XRTA, BF75AX LRTA, BF75AX XRTA, BF75AY LRTA, BF75AY XRTA, BF90A1 JRTA, BF90A1 LRTA, BF90A1 XRTA, BF9
06323-ZW1-V11

06323-ZW1-V11 PANEL KIT, SWITCH (DUAL) (Honda Code 6247415).
BF75A1 LRTA, BF75A1 XRTA, BF75A2 LRTA, BF75A2 XRTA, BF75AT LRTA, BF75AT XRTA, BF75AW LRTA, BF75AW XRTA, BF75AX LRTA, BF75AX XRTA, BF75AY LRTA, BF75AY XRTA, BF90A1 JRTA, BF90A1 LRTA, BF90A1 XRTA, BF90A2 JRTA, BF90A2 LRTA, BF90A2 XRTA, BF90A4 JRTA, BF9
35634-ZW5-U11

35634-ZW5-U11 PANEL, SOLENOID (Honda Code 7515273).
BF115A1 LA, BF115A1 LCA, BF115A1 XA, BF115A1 XCA, BF115A2 LA, BF115A2 LCA, BF115A2 XA, BF115A2 XCA, BF115A3 LA, BF115A3 LCA, BF115A3 XA, BF115A3 XCA, BF115A4 LA, BF115A4 LCA, BF115A4 XA, BF115A4 XCA, BF115A5 LA, BF115A5 LCA, BF115A5 XA, BF115A5 XCA,
06323-ZW1-V03

06323-ZW1-V03 PANEL KIT, SWITCH (SINGLE) (Honda Code 7225410).
BF75A2 LRTA, BF75A2 XRTA, BF75A3 LRTA, BF75A3 XRTA, BF75A4 LRTA, BF75A4 XRTA, BF90A2 JRTA, BF90A2 LRTA, BF90A2 XRTA, BF90A3 JRTA, BF90A3 LRTA, BF90A3 XRTA, BF90A4 JRTA, BF90A4 LRTA, BF90A4 XRTA
