Parameter Descriptions
Injector Codes
Note: The injector codes are not part of the "Configuration" screen on Cat ET. "Injector Codes Calibration" can be found under "Calibrations" in the "Service" menu on Cat ET.The injector code is a number that is found on each of the unit injectors. The ECM uses this number to compensate for manufacturing variations between individual injectors. If you replace any of the unit injectors, you must reprogram the code for the new injectors. Also, if you replace the ECM, you must reprogram all of the injector codes."Equipment ID"
The "Equipment ID" parameter allows the customer to enter a description into the ECM in order to identify the machine. A maximum of 17 characters can be entered in the field."Engine Serial Number"
Program the "Engine Serial Number" to match the engine serial number that is stamped on the engine information plate. The engine serial number is not preprogrammed on a replacement ECM."FLS" (Full Load Setting)
"FLS" is a number that represents the adjustment to the fuel system that was made at the factory in order to fine tune the fuel system. The correct value for this parameter is stamped on the engine information ratings plate. Only change this value if the engine is rerated or if a new ECM is installed. Factory passwords are required."FTS" (Full Torque Setting)
"FTS" is similar to "FLS". Only change this value if the engine is rerated or if a new ECM is installed. Factory passwords are required."Engine Oil Weight"
Do not program this parameter. Ensure that the proper oil grade plug is installed. Refer to Operation and Maintenance Manual, "Engine Oil and Filter - Change".System Configuration Parameters
Table 1
System Configuration Parameters
Parameter    Available Range or Options    Default    Required Password
ECM Identification Parameters
"Equipment ID"     Unprogrammed Software     Blank     None
"Engine Serial Number"     0XX00000
or
XXXX00000     Blank     None
System Parameters
"Full Load Setting (FLS)"     Factory Calibration     Factory
"Full Torque Setting (FTS)"     Factory Calibration     Factory
Selected Engine Rating
"Engine Oil Weight"     "Auto Detect ON"
"Auto Detect OFF"
"0W20"
"10W30"
"15W40"     "Auto Detect ON"     Factory    Parameter Worksheets
Record the following information before you change any programmable parameter.
Table 2
Engine Parameters
"Equipment ID"

"Engine Serial Number"

"ECM Serial Number"

"Personality Module Part Number"

"Personality Module Description"

"Personality Module Release Date"

"FLS"

"FTS"

"Rated Power"

"Rated Peak Torque"

"Top Engine Speed Range"

"Test Spec"

"Engine Oil Weight"

"Total Tattletale"

Injector Code (1)

Injector Code (2)

Injector Code (3)

Injector Code (4)

Injector Code (5)

Injector Code (6)

Table 3
Information from Engine Information Plate
Engine Serial Number

Fuel Air Ratio(for new ECM)

Full Load Setting (for new ECM)

Full Torque Setting (for new ECM)
   Note: Compare the "FLS" and the "FTS" from the ECM with the values that are listed on the engine information plate. Only change the "FLS" and the "FTS" under special circumstances. The use of the wrong parameters could cause damage to the engine. The use of the wrong parameters may also void the Caterpillar warranty.
