START BY:a. remove flywheel
Any time the crankshaft seal is removed from the wear sleeve, a new sleeve and seal must be installed as a unit. If the old seal is put back on the sleeve, the seal will be damaged.
1. Remove the bolts from adapter (1). Install two 5/16" - 18 NC forcing screws in the adapter to remove it from the flywheel housing. On machines that do not have adapter (1), use tooling (C) to remove the lip seal from the flywheel housing bore. 2. Remove O-ring seal (3) and crankshaft seal (2) from adapter (1). 3. Install tool (B) in the adapter bore as shown.4. Install tool (A) between tool (B) and wear sleeve (4). Turn tool (A) until the edge of the tool makes a flat place (crease) in the wear sleeve. Do this several places around the wear sleeve until the sleeve can be removed from the end of the crankshaft by hand.Install Crankshaft Rear Seal And Wear Sleeve
Any time the crankshaft seal is removed from the wear sleeve, a new sleeve and seal must be installed as a unit. If the old seal is put back on the sleeve, the seal will be damaged.
1. Install adapter (3) on tooling (A) as shown.
If the crankshaft seal and wear sleeve come apart during installation, the seal and sleeve become scrap, and a new seal and sleeve as a unit must be used as a replacement.
The rear seal and wear sleeve can not be exchanged with the front seal and wear sleeve. There are grooves in the sealing lip of the seals that direct the oil back into the crankcase as the crankshaft turns. An exchange of front and rear seals can cause the oil to come out of the crankcase.2. Put crankshaft seal (2) and wear sleeve (1) as a unit in position on adapter (3). Make sure the lip of the seal is up as shown. Install the O-ring seal on adapter (3).3. Install tool (B) over the studs of tooling (A). Install nuts (C), and tighten the nuts evenly until the seal is against the bottom of the adapter bore.4. Remove nuts (C), tool (B) and tooling (A) from the adapter.
Do not put engine oil on the seal during installation. Lubrication of the seal at installation can give a false indication of leakage at a later time.
5. Clean the outer surface of the crankshaft with 6V1541 Quick Cure Primer.6. Put clean engine oil on the O-ring seal, and install the seal on the adapter and put 9S3265 Retaining Compound on the outside diameter of the crankshaft and the inside diameter of the wear sleeve. 7. Install tooling (D) on the end of the crankshaft.8. Install guide bolts (E) in the drive housing. Put adapter (3) in position on guide bolts (E) and over tooling (D). Make sure the wear sleeve makes contact with the end of the crankshaft. 9. Install tool (B) over the small outside diameter of tool (F) until tool (B) is against the shoulder on tool (F).10. Install tooling (B) and (F) as a unit on the guide bolts and over locator.11. Put clean multi-purpose grease on the face of nut (G), and install nut (G) on the locator. Tighten nut (G) until the wear sleeve and adapter are in position.12. Remove the tooling from the engine. On engines that do not have adapter (3), use tool (H) in place of tooling (B) and (F). 13. Install bolts (4) to hold adapter (3) in position.END BY:a. install flywheel
