Introduction
This Special Instruction provides procedure to install double pole disconnect switch on certain C175 generator set engines.Do not perform any procedure in this Special Instruction until you have read the information and you understand the information.Safety Section
Use only proper tools and observe all precautions that pertain to the use of those tools. Failure to follow these procedures can result in personal injury. The following procedures should also be observed.Work safely. Most accidents that involve product operation, maintenance, and repair are caused by failure to observe basic safety rules or precautions. An accident can often be avoided by recognizing potentially hazardous situations before an accident occurs.A person must be alert to potential hazards. This person should also have the necessary training, skills, and tools to perform these functions properly.Safety precautions and warnings are provided in this instruction and on the product. If these hazard warnings are not heeded, bodily injury or death could occur to you or to other persons. Caterpillar cannot anticipate every possible circumstance that might involve a potential hazard.Therefore, the warnings in this publication and the warnings that are on the product are not all inclusive. If the tools, the procedure, the work method, or your actions are not recommended by Caterpillar, ensure that the tools and your actions are safe for you and for others.Ensure that the product will not be damaged or the product will be made unsafe by the operation, lubrication, maintenance, or the repair procedures.Follow all safety warnings. Most accidents that involve product operation, maintenance, or repair are caused by failure to observe safety warnings. An accident can often be avoided by recognizing potentially hazardous situations before an accident occurs. Personnel should be properly trained to perform maintenance, repair, or operate any machine. Safety precautions and warnings are provided this instruction and on Caterpillar products. These warnings should be observed before performing any procedures. Caterpillar cannot anticipate every possible circumstance that might involve a potential hazard. The warnings in this publication and on the product are not all inclusive.
Do not operate or work on this product unless you have read and understood the instruction and warnings in the relevant Operation and Maintenance Manuals and relevant service literature. Failure to follow the instructions or heed the warnings could result in injury or death. Proper care is your responsibility.
Failure to follow all safety guidelines prescribed in this document and by governing authorities and regulatory agencies may result in severe injury or death of personnel or machine damage.
When removing a major component or attachment, ensure that it is properly blocked or secured before removing mounting hardware. An assembly that is disconnected without proper blocking may shift or fall, resulting in serious injury or death of personnel or machine damage.
Climbing equipment may be required to access this service point. Refer to the Operation and Maintenance Manual, "Mounting and Dismounting" topic for safety information.
Before servicing/performing maintenance on the machine, electrical power must be physically disconnected; battery plugs must be disconnected from the batteries, or the trailing cable must be unplugged, and warning tags and padlocks shall be applied by a certified electrician. Certified electricians shall perform or direct any electrical work, including any energized testing, repair work in controllers, motors, or other approved compartments, and shall insure that all compartments are properly closed and inspected prior to re-energization. All applicable lock out and tag out procedures must be followed.
Do not operate the machine if any guards or covers are missing or inadequately secured. Personnel could be seriously injured or machine damage may occur.
Observe the safe working load limits of all lifting and blocking devices and keep a safe distance from suspended/blocked loads. Personnel may be seriously injured or killed by falling loads.
Required Parts
Table 1
Parts List
Generator Sets Qty Part
C175-16 1 463-6561 Disconnect Switch Gp
C175-20 1 463-6561 Disconnect Switch Gp Installation Procedure
Perform the below procedure to install the double pole disconnect switch.For C175-16 Generator Sets
Illustration 1 g06303305
View of holes location on left hand mounting rail
(A) 3565.5 mm (140.37 inch)
(B) 3498 mm (137.7 inch)
(C) 224.9 mm (8.85 inch)
Drill two parallel holes of diameter 13.5 mm (0.53 inch) on left hand mounting rail with reference to dimension (A), dimension (B), and dimension (C) as shown in Illustration 1.
