Illustration 1 g01478066
Schematic of the diagnostic connector and the data link connector
Illustration 2 g01458479
View of the P1 pin locations for the diagnostic and data link connectors
(23) Data link +
(24) Data link -
Illustration 3 g01478083
View of the P2 pin locations for the diagnostic and data link connectors (if equipped)
(20) Data link -
(21) Data link + Test Step 1. Inspect Electrical Connectors and WiringRefer to the troubleshooting guide for the machine in order to check the machine wiring between the P1 connector on the engine ECM and the diagnostic connector.Expected Result:There are no faults in the machine wiring.Results:
OK - Proceed to Test Step 2.
Not OK - Repair: Perform the following repair:Repair the connectors and/or the harness. Refer to the troubleshooting guide for the machine.Use the electronic service tool in order to clear all logged diagnostic codes and then verify that the repair eliminates the fault.STOPTest Step 2. Change the Electronic Service Tool Components
If another electronic engine is available, connect the electronic service tool to the other engine. Ensure that the same cables are used.
Turn the keyswitch to the ON position. Determine if the electronic service tool operates correctly on the other engine.
If another engine is not available, obtain a replacement communications adapter and a replacement set of cables. Ensure that the set of cables for the electronic service tool are a complete set.
Install the replacement communications adapter and the set of cables for the electronic service tool and connect to the diagnostic connector.
Turn the keyswitch to the ON position.
If changing the communications adapter or the cables allows the electronic service tool to operate correctly, use the following procedure:
Replace the components from the new set of cables with components from the old set of cables. Replace one component at a time.
Apply power to the electronic service tool after each of the components is replaced. Use this method to find the faulty component.
If changing the cables does not allow the electronic service tool to operate correctly, connect another electronic service tool.
Turn the keyswitch to the ON position. Expected Result:Result 1 The original electronic service tool works on another engine.Result 2 A different electronic service tool works on the original engine while the engine is being tested.Results:
Result 1 - Proceed to Test Step 3.
Result 2 - Repair: Send the faulty electronic service tool for repairs.STOPTest Step 3. Check the ECM
Make sure that the latest flash file for the application is installed in the ECM. Refer to Troubleshooting, "Flash Programming".
Use the electronic service tool to check the data link.
If the data link is not operating correctly, contact the technical communicator at a Caterpillar dealer. Note: This consultation can greatly reduce the repair time.
If necessary, install a test ECM. Refer to Troubleshooting, "Replacing the ECM".
Use the electronic service tool to verify that the fault is eliminated.
If the fault is eliminated with the test ECM, reconnect the suspect ECM. Verify that the fault returns.
If the fault returns with the suspect ECM, replace the ECM. Expected Result:The data link is operating correctly.Results:
OK - Repair: The data link is operating correctly.STOP
Not OK - Repair: The data link is not operating correctly. Perform the following procedure:
Contact the technical communicator at a Caterpillar dealer. Note: This consultation can greatly reduce the repair time.
If necessary, install a test ECM. Refer to Troubleshooting, "Replacing the ECM".
Use the electronic service tool to verify that the fault is eliminated.
If the fault is eliminated with the test ECM, reconnect the suspect ECM. Verify that the fault returns.
If the fault returns with the suspect ECM, replace the ECM. STOP
