1. Install the camshaft bearings in the fuel injection pump housing with tool (C). Install the bearing in governor end of housing so the lubrication hole in the bearing is in alignment with lubrication hole in housing. Install the camshaft bearings even with outside ends of fuel injection pump housing.
Install the rack bearing in the governor end of the housing with the small holes in the bearing parallel to the vertical centerline of the pump.
2. Install the rack bearing in the governor end of the housing with tooling (F). Install the bearing so it will be .195 .005 in. (4.95 0.13 mm) inside the face of the housing.
Tooling (D) must be used to install the rack bearing in the accessory drive end of the housing. This will put the tab on the bearing in its correct position and install the bearing to the correct depth.
3. Install the rack bearing in the accessory drive end of the housing with tooling (D).4. Put clean engine oil on camshaft. Install the camshaft in fuel injection pump housing. 5. Put the governor drive gear (1) and spring (2) in position on the camshaft. Install the camshaft plate (3), bolt and lock. 5. Install lifters (4) in their correct positions in the housing. Put clean engine oil on the rack. Install rack (5) in the fuel injection pump housing with the opening in the rack near the governor end of the housing.6. Install the spacers in their respective positions in the housing. When new lifters and pumps are installed, it is necessary to make adjustment of the fuel pump timing. See FUEL INJECTION PUMP TIMING DIMENSIONS SETTING, OFF ENGINE in TESTING AND ADJUSTING.7. Assemble the fuel injection pumps as follows:a) Put clean fuel oil on all parts.b) Install the spring on the barrel.c) Install the washer on the plunger and gear segment. Install the plunger in the barrel.d) Install the spring and check valve in the bonnet.e) Put the bonnet in position on the barrel and install the ring to hold the unit together.f) Install the seal on the bonnet.
Make sure the fuel rack is in the center (zero) position before the fuel injection pumps are installed.
8. Put the rack in the center position with tooling (E) as follows:a) Install location fixture (6) on the fuel injection pump housing. b) Install the gauge (7). Move the gauge (7) to zero. Push the rack (5) against the gauge.c) Install the clamp (8) on pump housing as illustrated. This will keep the rack in the center when the fuel injection pumps are installed. 9. With the rack in the center, install the fuel injection pumps as follows:a) Turn the camshaft until the lobe of the camshaft is down for the pump to be installed.b) Install tool (B) on the pump.c) Put the grooves (9) in the bonnet and barrel in alignment with the groove (10) in the pump gear segment. Put the pump in position so the grooves are in alignment with the guide pins in the housing bore. Install the pump in its correct position in the housing. d) Install bushing (11) over the bonnet. Install tool (B) on the bonnet and push down on tool (B). Tighten bushing (11) by hand until the bushing is even with top of housing. If installation of the bushing can not be made this far by hand, remove it. Remove the pump, put the parts in alignment again and install the bushing again.
If installation of pump is correct, the bushing can be tightened by hand until it is even with face of pump housing.
e) Make a check of the rack travel after each pump is installed as follows:Move clamp (8) away from the end of the rack. Use gauge (7) to measure the rack movement. The total rack movement must be .800 in. (20.32 mm). If the rack can not be moved this distance, the pump gear segment is not in the correct position and the pump must be removed and installed again. f) Remove the tool (B) and tool (E). Install tool (A) and turn retaining bushing to a torque of 150 10 lb.ft. (205 14 N m). Remove tool (A). Install the washers and protection caps for fuel injection pumps.end by:a) connection of governor to fuel injection pump housingb) install fuel injection pump housing and governorc) adjust governor and set the rack (See GOVERNOR ADJUSTMENTS and FUEL RACK SETTING in TESTING AND ADJUSTING)Remove Fuel Transfer Pump
1. Remove bolts (1).2. Remove fuel transfer pump (2). 3. Remove the service meter (3) from the fuel transfer pump.Install Fuel Transfer Pump
1. Install service meter (1) on the fuel transfer pump (2).2. Put the fuel transfer pump in position on the engine. Install the bolts that hold the fuel transfer pump in position.Disassemble Fuel Transfer Pump
start by:a) remove fuel transfer pump1. Remove the service meter from the transfer pump. 2. Remove nut (2), gear (3) and the key from the end of the shaft assembly.3. Remove cage assembly (1) from the shaft assembly.4. Remove the O-ring seals and the ring from the outside of cage assembly (1). 5. Use tool group (A) to remove the two seals and bushing from the inside of cage assembly (1).
Use care not to damage the contact surfaces of the body and cover assemblies when the pump is disassembled and assembled.
6. Remove the screws and make a separation of cover assembly (5) from the body assembly.7. Remove the bolt, gasket, spring and plunger assembly from the side of cover assembly (5).8. Remove the lip type seal from cover assembly (5).9. Remove gear (4) and shaft assembly (6) from the body assembly. 10. Use tool group (A) to remove the bushing from the body assembly.Assemble Fuel Transfer Pump
See SPECIAL INSTRUCTION Form GMG00578 for instructions to use tool group (C).1. Clean all parts thoroughly before the transfer pump is assembled. 2. Install bearing (2) in body assembly (1) with tooling (A). Make sure the face of the bearing is not beyond
