Illustration 1 g00286672
Illustration 2 g00286673
When the electric starting motor is viewed from the drive end, the motor rotates in the following direction. ... ClockwiseNo load conditions at 25°C (77°F) Speed ... 6900 1800 rpm Current draw ... 127.5 27.5 amp Voltage ... 11 V (1) Tighten the nut on the battery terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (2) Tighten the nut on the ground terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (3) Tighten the nut on the ground terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (4) Tighten the nut on the switch terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (5) Tighten the nut on the motor terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (6) Tighten the nut on the motor frame terminal to the following torque. ... 8 3 N m (70.8 26.6 lb in) 3E-5449 Starting Motor Solenoid Assembly Current consumption at 25°C (77°F) Pull-in windings at 10V ... 92.5 7.5 Amp Hold-in windings at 10V ... 23 AmpType 2
Illustration 3 g00286676
Illustration 4 g00286677
When the electric starting motor is viewed from the drive end, the motor rotates in the following direction. ... ClockwiseNo load conditions at 25°C (77°F) Speed ... 5500 rpm minimum Current draw ... 140 Amp maximum Voltage ... 24 V (1) Tighten the nut on the ground terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (2) Tighten the nut on the battery terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (3) Tighten the nut on the ground terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (4) Tighten the nut on the switch terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (5) Tighten the nut on the motor terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (6) Tighten the nut on the motor frame terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) 9X-0332 Solenoid Kit Current consumption at 25°C (77°F) Pull-in windings at 24V ... 51 Amp Hold-in windings at 24V ... 7 AmpType 3
Illustration 5 g00286672
Illustration 6 g00286673
When the electric starting motor is viewed from the drive end, the motor rotates in the following direction. ... ClockwiseNo load conditions at 25°C (77°F) Speed ... 7643 1683 rpm Current draw ... 76.5 7.5 amp Voltage ... 23 V (1) Tighten the nut on the battery terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (2) Tighten the nut on the ground terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (3) Tighten the nut on the ground terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (4) Tighten the nut on the switch terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (5) Tighten the nut on the motor terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (6) Tighten the nut on the motor frame terminal to the following torque. ... 8 3 N m (70.8 26.6 lb in) 9X-9511 Solenoid Assembly Current consumption at 25°C (77°F) Pull-in windings at 20V ... 56.5 4.5 Amp Hold-in windings at 20V ... 14.6 AmpType 4
Illustration 7 g00916190
Illustration 8 g00916414
When the electric starting motor is viewed from the drive end, the motor rotates in the following direction. ... ClockwiseNo load conditions at 25°C (77°F) Speed ... 6950 1650 rpm Current draw ... 115 25 amp Voltage ... 23 V (1) Tighten the nut on the battery terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (2) Tighten the nut on the ground terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (3) Tighten the nut on the ground terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (4) Tighten the nut on the switch terminal to the following torque. ... 2.25 0.25 N m (19.914 2.213 lb in) (5) Tighten the nut on the motor terminal to the following torque. ... 30 3.5 N m (22.1 2.58 lb ft) (6) Tighten the nut on the motor frame terminal to the following torque. ... 8 3 N m (70.8 26.6 lb in) 125-6533 Solenoid Assembly Current consumption at 25°C (77°F) Pull-in windings at 20V ... 49.3 3.3 Amp Hold-in windings at 20V ... 6.8 Amp
