Load the battery with a carbon pile (4C4911 Battery Load Tester) to get the maximum alternator output.Polarity ... Negative GroundRotation ... Either DirectionMinimum full load current at 5000 rpm ... 67AMinimum full load current at 2000 rpm ... 29AField current at rated voltage and 27°C (80°F) ... 2.5 to 2.9A(1) Torque for nut ... 102 7 N m (75 5 lb ft)(2) Torque for output terminal ... 13.5 1.3 N m (119.47 11.50 lb in)3T6354 Regulator (Inside Alternator)
Voltage Setting ... No AdjustmentPermissible Voltage Range ... 27 to 29V100-5045 Alternator 24V 50A
Load the battery with a carbon pile (4C4911 Battery Load Tester) to get the maximum alternator output.Polarity ... Negative GroundRotation ... Either DirectionSpeed for testing (rpm) ... 5000Output voltage ... 28 1.0VOutput (cold) ... 44.6ATorque for the ground terminal nut ... 4.4 1 N m (3 .7 lb ft)(1) Torque for the pulley nut ... 102 7 N m (75 5 lb ft)(2) Torque for the output terminal nut ... 13.5 1.3 N m (119.47 11.50 lb in)9G7567 Regulator (Under Alternator Cover). For use with the 100-5045 Alternator
Voltage rating ... 28VPolarity ... Negative GroundVoltage setting range ... 27 to 29V100-5046 Alternator 24V 50A
Load the battery with a carbon pile (4C4911 Battery Load Tester) to get the maximum alternator output.Polarity ... Negative GroundRotation ... Either DirectionSpeed for testing (rpm) ... 5000Output voltage ... 27.5 1.0VOutput (cold) ... 45ATorque for the ground terminal nut ... 2.25 .25 N m (1.65 .184 lb ft)(1) Torque for the pulley nut ... 102 7 N m (75 5 lb ft)(2) Torque for the output terminal nut ... 13.5 1.3 N m (119.47 11.50 lb in)9G7567 Regulator (Under Alternator Cover) For use with the 100-5046 Alternator
Voltage rating ... 28VPolarity ... Negative GroundVoltage setting range ... 26.5 to 28.5V3T6352 Alternator 24V 35A
Load the battery with a carbon pile (4C4911 Battery Load Tester) to get the maximum alternator output.Polarity ... Negative GroundRotation ... Either DirectionSpeed for testing (rpm) ... 5000Output voltage ... 28 1.0VOutput (cold) ... 35A(1) Torque for the ground terminal nut ... 2.25 .25 N m (19.9 2.2 lb in)(2) Torque for the pulley nut ... 102 7 N m (75 5 lb ft)(3) Torque for the output terminal nut ... 6.2 .6 N m (54.9 5.3 lb in)3T6354 Regulator (Inside Alternator)
Voltage setting ... No adjustmentPermissible voltage range ... 27 to 29V7N9720 Alternator 24V 35A
Typical Example Load the battery with a carbon pile (4C4911 Battery Load Tester) to get the maximum alternator output.Polarity ... Negative GroundRotation ... ClockwiseSpeed for testing (rpm) ... 5000Output voltage ... 27.5 1.0VOutput (cold) ... 35ATorque for the ground terminal nut ... 2.1 to 2.8 N m (19 to 25 lb in)(1) Torque for the pulley nut ... 102 7 N m (75 5 lb ft)(2) Torque for the output terminal nut ... 13.5 1.3 N m (119.47 11.5 lb in)9G7567 Regulator (Under Alternator Cover). For use with the 7N9720 Alternator.
Voltage rating ... 28VPolarity ... Negative GroundVoltage setting range ... 26.5 to 28.5V9G4574 Alternator 24V 35A
Load the battery with a carbon pile (4C4911 Battery Load Tester) to get the maximum alternator output.Polarity ... Negative GroundRotation ... Either DirectionSpeed for testing (rpm) ... 5000Output voltage ... 28 1.0VOutput (cold) ... 35.6A(1) Torque for the pulley nut ... 102 7 N m (75 5 lb ft)(2) Torque for the output terminal nut ... 13.5 1.3 N m (119.47 11.5 lb in)(3) Torque for the ground terminal nut ... 3.4 to 5.4 N m (31 to 49 lb in)
