This Revised Service Letter replaces the February 22, 1999 (Revised August 1999) Service Letter. Changes have been made to the TERMINATION DATE.
Termination Date
August 31, 2000Problem
The engine covers on certain AP-1050B and AP-1055B Asphalt Pavers; and on certain Barber-Greene BG-245C and BG-2455C Asphalt Pavers Manufactured by Caterpillar have been improved.
resulting in lower restriction and increased air flow. Ducting has also been added that directs exhaust air straight out the right side instead of down and to the rear. The left side ducting helps prevent debris from being drawn into the radiator off the track.
Affected Product
Model & Identification Number
AP-1050B (6ZN1-194)
AP-1055B (8BM1-390, 8BM394-396, 8BM398, 8BM414)
BG-245C (4XN1-122)
BG-2455C (6TN1-140)
Parts Needed
6 - 5C9553 BOLT1 - 2D6235 LOCKNUT10 - 4L6454 BOLT1 - 2M0849 WASHER1 - 5P0494 STUD8 - 5P1075 WASHER2 - 8T4122 WASHER-PLATE8 - 8T4205 WASHER-PLATE1 - 8T4223 WASHER16 - 8T4896 WASHER7 - 8T9364 BOLT6 - 6V8801 NUT1 - 6V8188 NUT2 - 7X0344 BOLT4 - 7X0515 WASHER6 - 9X8267 WASHER2 - 1296813 DECAL1 - 1701562 PLATE1 - 1701563 PLATE1 - 1704852 DEFLECTOR1 - 1705746 ANGLE1 - 1706622 FENDER AS2 - 1707747 COVER AS-LOUVER1 - 1708559 PANEL AS LH1 - 1708560 PANEL AS RH1 - 1708691 BRACKET1 - 1708703 DECAL1 - 1709040 FLASHING1 - 1709074 PLATE1 - 1711196 FLASHINGAction Required
See the attached procedure.
Service Claim Allowances
This is a 20-hour job.
Parts Disposition
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
Attach.(1-Rework Procedure)Rework Procedure
ENGINE COVER GP. REWORK PROCEEDURE
Parts required
Machines with High Ambient Oil Cooler Option
Parts required are the Basic Group and delete (1) 170-7747, add (1) 170-9177
PROCEDURE
1. Remove the side doors p/n 127-8514 and p/n 127-8515, refer to the Parts Manual KEBP0169-01. Retain the mounting hardware to be used for installation of the new doors.2. Remove the left and right angled louvered cover assemblies p/n 125-6528 and retain the hard ware.3. Disconnect the MPC-10 propel and material control module harnesses using a 4mm or ' allen wrench.4. Remove the MPC-10 propel and material control modules.5. Remove the MPC-10 mounting Bracket As. p/n 111-2159 and Plate As. p/n 112-4272, refer to the Installation Gp.- Electrical in the Parts Manual KEBP0169-01.6. Drill and tap six -20NC holes as shown in Illustration #1 and install 171-1196 / 170-9040 flashings and 170-5746 angle as shown in Illustration #2.7. Drill and tap four -16NC holes as shown in Illustration #4.8. Install the new MPC-10 mounting brackets and controllers as shown in Illustration #6.9. Install the left side ducting and door as shown in Illustration #3.10. Rework 170-6622 Fender as shown in Illustration #7.11. Install the left and right upper louvered cover assemblies 170-7747 both sides. Note; the left upper louvered cover assembly 170-9177 must be substituted if the machine has the optional auxiliary oil cooler.
Illustration 1.Hole Location Detail For Lower Flashing Installation
Illustration 2.Lower Radiator Flashing Installation
Illustration 3.Left Side Ducting and Door Installation
Illustration 4.Rework the frame tube to add four -16 threaded mounting holes to attach 170-1563 Plate (lower duct) refer to Illustration 3
Illustration 5.Right side ducting installation (not required if the auxiliary fuel tank is installed)
.
Illustration 6.MPC-10 Mounting Bracket Installation
Illustration 7.170-8691 Bracket Assembly Rework
Illustration 8.170-8691 Bracket Assembly Rework
