69201 Mercruiser O-RING

Illustration 1 g00508403
Top View (1) Speed sensor or timing sensor (2) Coolant temperature sensor (3) Inlet air temperature sensor (if equipped) (4) Boost pressure sensor (5) Fuel temperature sensor (6) Fuel pressure sensor (if equipped) (7) Atmospheric pressure sensor
Illustration 2 g00508517
Front View (1) Speed sensor or timing sensor (2) Coolant temperature sensor (5) Fuel temperature sensor
Illustration 3 g00508514
Right Side View (8) Oil pressure sensor (if equipped)
Illustration 4 g00508405
Left Side View (5) Fuel temperature sensor (6) Fuel pressure sensor (7) Atmospheric pressure sensor (9) Engine wiring harness (10) Electronic Control Module (ECM)The electronic control system has the following major components:
(1) Speed sensor or timing sensor
(2) Coolant temperature sensor
(3) Inlet air temperature sensor
(4) Boost pressure sensor
(5) Fuel temperature sensor
(6) Fuel pressure sensor (if equipped)
(7) Atmospheric pressure sensor
(8) Oil pressure sensor
(9) Engine wiring harness
(10) Electronic Control Module (ECM)
A remote mounted throttle position sensorThe electronic control system is integrally designed into the engine's fuel system and the engine's air inlet and exhaust system in order to electronically control the fuel delivery and the injection timing. The electronic control system provides increased timing control and fuel air ratio control in comparison to conventional mechanical engines. Injection timing is achieved by precise control of injector firing time, and engine rpm is controlled by adjusting the firing duration. The ECM energizes the solenoid in the unit injector in order to start the injection of fuel. Also, the ECM de-energizes the unit injector solenoids in order to stop injection of fuel. Refer to Systems Operation/Testing And Adjusting, "Unit Injector" for a complete explanation of the fuel injection process.The engine uses the following three types of electronic components:
Input
Control
OutputAn input component is one that sends an electrical signal to the electronic control module of the system. The signal that is sent varies in either voltage or frequency. The variation of the signal is in response to a change in some specific system of the vehicle. The electronic control module sees the input sensor signal as information about the condition, environment, or operation of the vehicle.A control component receives the input signals. Electronic circuits inside the control evaluate the signals from the input components. These electronic circuits also supply electrical energy to the output components of the system. The electrical energy that is supplied to the output components is based on predetermined combinations of input signal values.An output component is one that is operated by a control module. The output component receives electrical energy from the electronic control group. The output component uses the electrical energy in one of two ways. The output component can use that electrical energy in order to perform work. The output component can use that electrical energy in order to provide information.
A moving solenoid plunger will perform work. By performing work, the component has functioned in order to regulate the vehicle.
A dash panel light or an alarm will provide information to the operator of the vehicle.These electronic components provide the ability to electronically control the engine operation. Engines with electronic controls offer the following advantages:
improvement in performance
improvement in fuel consumption
reduction in emissions levels
Table 1
Electrical Connectors and Functions
J/P No.     Function
J1/P1     ECM Connector (40 pin, OEM Harness Connector
J2/P2     ECM Connector (40 pin, Engine Harness Connector
J3/P3     Boost Pressure Sensor Connector (3 pin)
J5/P5     Fuel Injector Connector (12 pin)
J9/P9     Speed Sensor or Timing Sensor Connector (3 pin)
J10/P10     Coolant Temperature Sensor Connector (3 pin)
J11/P11     Throttle Position Sensor Connector (3 pin)
J12/P12     Transmission Switch Speed Output
J17/P17     Fuel Pressure Sensor Connector (3 pin)
J21/P21     Inlet Manifold Temperature Sensor Connector (3 pin)
J22/P22     Atmospheric Pressure Sensor Connector (3 pin)
J23/P23     Fuel Temperature Sensor Connector (3 pin)
J24/P24     TC Connector (2 pin)
