Illustration 1 g00603959
Illustration 2 g00604063
View A-A
Illustration 3 g00604055
View B-B
3E-7578 Alternator Gp 3T-1888 Alternator Gp 112-5041 Alternator Gp 112-5041 Alternator Gp Note: Load the battery with a carbon pile 4C-4911 Battery Load Tester in order to get the maximum alternator output.Voltage rating ... 24 VoltPolarity ... Negative groundRotation ... Either directionThe maximum turn on speed at 25 °C (77 °F) is the following value. ... 2000 RPMThe output voltage at 25 °C (77 °F) is the following value. ... 28 1 VoltThe minimum full load current at 5000 rpm is the following value. ... 47 AmpThe minimum full load current at 1500 rpm is the following value. ... 18 Amp (1) Tighten the shaft nut to the following torque. ... 102 7 N m (75 5 lb ft) (2) Tighten the negative ground terminal screw to the following torque. ... 6.2 0.6 N m (55 5 lb in) (3) Tighten the positive output terminal nut to the following torque. ... 13.5 1.3 N m (120 12 lb in) (4) Regulator
Illustration 4 g00604282
Illustration 5 g00604309
View A-A
3E-8827 Alternator Gp 121-4135 Alternator GpNote: Load the battery with a carbon pile 4C-4911 Battery Load Tester in order to get the maximum alternator output.Voltage rating ... 12 VoltPolarity ... Negative groundRotation ... Either directionThe maximum turn on speed at 25 °C (77 °F) is the following value. ... 2000 RPMThe output voltage at 25 °C (77 °F) is the following value. ... 14 0.5 VoltThe minimum full load current at 5000 rpm is the following value. ... 119 AmpThe minimum full load current at 1500 rpm is the following value. ... 41 Amp (1) Tighten the shaft nut to the following torque. ... 102 7 N m (75 5 lb ft) (2) Tighten the positive output terminal nut to the following torque. ... 11.3 N m (100 lb in) (3) Tighten the negative ground terminal nut to the following torque. ... 6.2 0.6 N m (55 5 lb in) 9X-6796 Alternator Gp 121-4134 Alternator Gp Note: Load the battery with a carbon pile 4C-4911 Battery Load Tester in order to get the maximum alternator output.Voltage rating ... 12 VoltPolarity ... Negative groundRotation ... Either directionThe maximum turn on speed at 25 °C (77 °F) is the following value. ... 2000 RPMThe output voltage at 25 °C (77 °F) is the following value. ... 14 0.5 VoltThe minimum full load current at 5000 rpm is the following value. ... 107 AmpThe minimum full load current at 1500 rpm is the following value. ... 45 Amp (1) Tighten the shaft nut to the following torque. ... 102 7 N m (75 5 lb ft) (2) Tighten the positive output terminal nut to the following torque. ... 11.3 N m (100 lb in) (3) Tighten the negative ground terminal nut to the following torque. ... 6.2 0.6 N m (55 5 lb in)
Illustration 6 g00604347
Illustration 7 g00604355
View A-A
3T-6352 Alternator Gp 6N-9294 Alternator Gp Note: Load the battery with a carbon pile 4C-4911 Battery Load Tester in order to get the maximum alternator output.Voltage rating ... 24 VoltPolarity ... Negative groundRotation ... Either directionThe maximum turn on speed at 25 °C (77 °F) is the following value. ... 2000 RPMThe output voltage at 25 °C (77 °F) is the following value. ... 28 1 VoltThe minimum full load current at 5000 rpm is the following value. ... 35 AmpThe minimum full load current at 1500 rpm is the following value. ... 11 Amp (1) Tighten the shaft nut to the following torque. ... 102 7 N m (75 5 lb ft) (2) Tighten the positive output terminal nut to the following torque. ... 6.2 0.6 N m (55 5 lb in) (3) Tighten the negative ground terminal nut to the following torque. ... 2.25 0.25 N m (20 2 lb in) (4) Regulator
Illustration 8 g00604364
Illustration 9 g00604375
View A-A
4N-3986 Alternator GpNote: Load the battery with a carbon pile 4C-4911 Battery Load Tester in order to get the m
