Introduction
This Special Instruction is intended to provide information on the Engine Overhaul Kit Consist and detailed information on specific parts that should be used based on engine arrangements.This Engine Overhaul Kit may contain extra parts and extra quantities due to the variety of engine arrangements assigned to a given kit. Refer to the corresponding Parts Manual or Disassembly and Assembly manual in Table 1.Note: The 455-1194 Top End Overhaul Kit only applies to certain engine serial numbers. Verify that your engine serial number is listed in the tables found in the ""Pricing Arrangement Tables"" section below.Note: This Kit may contain upgraded parts. These upgraded part numbers may be different than what you have in the parts manual or engine, but these parts have been technically reviewed for compatibility with your application. Note: This kit contains gasket kits and includes additional parts needed to perform an engine overhaul.Note: For more information, visit us at: catmarinesupport.com.Note: For assistance with technical questions, contact your local Cat dealer. Reference Material
Table 1
Engine Model     Engine Arrangements     Engine Serial Number Prefix     Parts Book Media     Disassembly and Assembly Media
C18     261-7709     S/N:CYG     SEBP4317     RENR2389
242-0382
242-0376
242-0372 S/N:CYN
    SEBP4019     RENR2389
241-9639
241-9621
241-9620
241-9632 S/N:C1J     SEBP4018     RENR2389    Note: For ordering reference material, contact your local Cat dealer.C18 455-1194 Top End Overhaul Kit Consist
Table 2
455-1194 Top End Overhaul Kit Consist
Gasket Kits
Part Number     Part Name     Qty
453-2313     Heat Exchanger Gasket Kit     1
453-2315     Oil Cooler and Lines Gasket Kit     1
455-1617     After Cooler and Lines Gasket Kit     1
456-0005     Single Cylinder Head Gasket Kit     1
Additional Parts Included in This Kit
Part Number     Part Name     Qty
1R-0749     Fuel Filter     1
1R-1808     Engine Oil Filter     2
2N-2766     Locknut     12
2S-4078     O-Ring Seal     2
3K-0360     O-Ring Seal     2
6L-2280     Zinc Rod     3
6V-4589     O-Ring Seal     1
6V-5048     O-Ring Seal     4
6V-6923     Backup Ring     1
6V-8397     O-Ring Seal     2
8S-9191     Bolt     6
033-6033     O-Ring Seal     1
061-9455     O-Ring Seal     1
106-1792     Taperlock Stud     12
109-0072     O-Ring Seal     1
205-4832     O-Ring Seal     2
214-7568     O-Ring Seal     6
230-3728     O-Ring Seal     1
248-5513     Temperature Regulator     1
274-7913     Air Filter Element As     1
297-1813     Head Screw     12    C18 Engine Gasket Kit Locations
Illustration 1 g03686329
(1) Single Cylinder Head ( 456-0005 Gasket Kit ) (2) Aftercooler and Lines Kit ( 455-1617 Gasket Kit ) (3) Heat Exchanger ( 453-2313 Gasket Kit ) (4) Oil Cooler and Lines ( 453-2315 Gasket Kit )Gasket Kit Consists
Heat Exchanger (453-2313 Gasket Kit)
Table 3
453-2313 Gasket Kit (Heat Exchanger)
Part Number     Part Name     Qty
3K-0360     O-Ring Seal     2
3S-9643     Lip Type Seal     1
6V-9027     O-Ring Seal     2
8C-3073     O-Ring Seal     1
204-7844
