Illustration 1 g02840856
Front view
Illustration 2 g02852037
Bolt tightening sequence
Table 1
Specification for 350-5225 Cylinder Block Gp
Item Qty Part Specification Description
A 16 8T-0099 Dowel Extension from top face of the cylinder block is 20.0 0.5 mm (0.79 0.02 inch).
B 8 362-9677 Spacer Plate During assembly, bottom of the plate, top of block, and both sides of plate gasket must be free from of fuel, oil, water, gasket adhesives, assembly compounds or any other contaminates.
Thickness of one plate is 12.333 mm (0.4856 inch).
C 8 144-5692 Plate Gasket Thickness of one gasket between the cylinder block and spacer plates is 0.182 to 0.220 mm (0.0072 to 0.0087 inch).
D 8 197-7008 Dowel Extension from top face of the cylinder block is 21.0 0.5 mm (0.83 0.02 inch).
1 2 4W-4813 Plug Torque to 100 15 N m (74 11 lb ft).
E - - New dimension from centerline of crankshaft bearing bore to the top of the block is 586.00 mm (23.071 inch).
2 5 223-1696 Crankshaft Bearing Cap Width of main bearing (F) is 340.030 0.015 mm (13.3870 0.0006 inch).
Width of cylinder block for main bearing cap is 339.985 0.015 mm (13.3852 0.0006 inch).
Tight press fit between the sides of the main bearing cap and the cylinder block is 0.075 mm (0.0030 inch).
Loose press fit between the sides of the main bearing cap and the cylinder block is 0.015 mm (0.0006 inch).
G - - New dimension from centerline of crankshaft bearing bore to bottom of block (pan rails) is 230 mm (9.1 inch).
3 20 7X-7925 Bolt Use the following procedure in order to tighten the bolts (3):
1. Install main bearing caps with the part number and FRONT toward the front of the block. Each cap has a number. Each cap must be installed in the same position as the correct number on the side of the cylinder block pan rail.
2. Before assembly, apply clean engine oil to the threads of the bolts.
3. Tighten the bolt in the numerical sequence as shown in Illustration 2 to 190 14 N m (140 10 lb ft).
4. Again, tighten the bolt in the numerical sequence as shown in Illustration 2 to an angle of 180 5 degrees.
Illustration 3 g02840857
Front view
Table 2
Specification for 350-5225 Cylinder Block Gp
Item Qty Part Specification Description
4 8 211-7826 Cylinder Block Liner For the correct method of determining height of the liner, refer to Testing and Adjusting, "Cylinder Liner Projection".
5 8 352-6061 Liner Seal Before assembly, cover seals with either P-80 Rubber Lubricant Emulsion or liquid soap.
Assemble dry seals on clean and dry liner grooves.
H - - Bore in the block for the camshaft bearings is 98.000 0.020 mm (3.8583 0.0008 inch).
J - - Oil holes must be positioned from horizontal at angle of 20 5 degrees.
All centerlines through oil holes in the camshaft bearings and bearing junctions must be in the position that is shown for each side of the cylinder block.
6 24 7N-2046 O-Ring Seal Before assembly, cover seals with either P-80 Rubber Lubricant Emulsion or liquid soap.
7 8 6V-3348 O-Ring Seal Before assembly, lightly lubricate the bore with the lubricant that is being sealed.
K - - Bore in the block for the main bearings is 169.742 0.020 mm (6.6827 0.0008 inch).
Illustration 4 g02840858
Right side view
