Table 1
Event Code
Code and Description     Conditions which Activate the Code    System Response
E039(2) Low Engine Oil Pressure Derate     The engine oil pressure is less than the trip point and the delay time has expired.     The engine will be derated. The code is logged.
E040(3) Low Engine Oil Pressure Shutdown     Fuel injection is disabled. The code is logged. The engine is shut down.
E100(1) Low Engine Oil Pressure Warning     The code is logged.
E099(1) Engine Oil Filter Restriction Warning     The oil filter differential pressure is greater than the trip point.     The code is logged.    Probable Causes
Low engine oil level
Contaminated engine oil
Incorrect viscosity
Faulty oil pressure sensors
Improper circulation of the engine oil
Worn componentsRecommended Repairs
Low Engine Oil Level
Check the oil level. Add oil, as needed.Contaminated Engine Oil
Engine oil that is contaminated with another liquid will cause low engine oil pressure. High engine oil level can be an indication of contamination. Obtain an analysis of the engine oil. Determine the reason for contamination of the engine oil and make the necessary repairs. Change the engine oil and the engine oil filter. For the correct engine oil to use, refer to the Operation and Maintenance Manual.Incorrect Viscosity
Make sure that the engine is supplied with the correct engine oil. For the correct engine oil to use, refer to the Operation and Maintenance Manual.Faulty Engine Oil Pressure Sensors
Use Caterpillar Electronic Technician (ET) to compare the readings of the filtered engine oil pressure and the unfiltered engine oil pressure. Compare the pressures while the engine is OFF. Both readings should be close to zero pressure.If a reading is different from zero, refer to Troubleshooting, "Sensor Signal (Analog, Active) - Test".Improper Circulation of the Engine Oil
Several factors could cause improper circulation of the engine oil:
The engine oil filter is clogged. Replace the engine oil filter.
An engine oil line or a passage for engine oil is disconnected or broken.
The engine oil cooler is clogged. Thoroughly clean the engine oil cooler.
There is a problem with a piston cooling jet. Breakage, a restriction, or incorrect installation of a piston cooling jet will cause seizure of the piston.
The inlet screen of the suction tube for the engine oil pump can have a restriction. This restriction will cause cavitation and a loss of engine oil pressure. Check the inlet screen on the suction tube and remove any material that may be restricting engine oil flow.
The suction tube is drawing in air. Check the joints of the tube for cracks or for a damaged O-ring seal.
There is a problem with the engine oil pump. Check the gears of the engine oil pump for excessive wear. Engine oil pressure is reduced by gears that have too much wear.
The engine oil pump pressure regulating valve or a bypass valve is stuck in the open position. Clean the valve. Replace parts, if necessary.Worn Components
Excessive clearance at the crankshaft or camshaft bearings will cause low engine oil pressure. Also, inspect the clearance between the rocker arm shafts and the rocker arms. Check the engine components for excessive clearance.Obtain an analysis of the engine oil. Check the analysis for the level of wear metals in the engine oil.
