Table 1
CDL Code and Description J1939 Code and Description Comments
168-2
Electrical System Voltage : Erratic, Intermittent, or Incorrect 168-2
Electrical System Voltage : Erratic, Intermittent, or Incorrect The engine is running. The battery voltage falls below 6 VDC and the voltage returns above 9 VDC for three voltage readings in the last 7 seconds.
168-3
Electrical System Voltage : Voltage Above Normal 168-3
Electrical System Voltage : Voltage Above Normal The ECM detects voltage that is above the acceptable value.
168-4
Electrical System Voltage : Voltage Below Normal 168-4
Electrical System Voltage : Voltage Below Normal The ECM detects voltage that is below the acceptable value.
1834-2
Ignition Key Switch loss of signal 158-2
Ignition Key Switch loss of signal The ECM detects an erratic signal from the keyswitch because the keyswitch was cycled at least three times in the last second The engine ECM requires the keyswitch to be in the ON position in order to maintain communications with Cat® Electronic Technician (ET).
Illustration 1 g06274868
Table 2
1. Determine the Diagnostic Code
A. Establish communication between the Cat ET and the ECM . Refer to Troubleshooting, "Electronic Service Tools", if necessary.
B. Start the engine. Run the engine until the engine is at normal operating temperature.
C. Observe the "Active Diagnostic" screen on Cat ET. Wait at least 30 seconds so that any codes may become active.
Diagnostic code
Result: A 168-2, 158-2 or a 1834-2 diagnostic code is active.
Proceed to Test Step 2.
Result: A -3 or -11 diagnostic code is active.
Proceed to Test Step 3.
Result: A -4 diagnostic code is active.
Proceed to Test Step 4.
2. Inspect the Electrical Connectors and the Wiring For the Charging Circuit
A. Turn the keyswitch to the OFF position.
B. Check the harness connections at the battery and at the alternator.
C. Check the harness between the battery and the alternator.
Electrical connectors
Result: The harness and connectors appear to be OK.
There is a problem with the charging system. Refer to Special Instruction, REHS0354, "Charging System Troubleshooting".
Result: The connectors and/or wiring are not OK.
Repair the wiring and/or the connectors. Replace parts, if necessary. Ensure that all of the seals are properly in place and ensure that the connectors are coupled. Verify that the repair eliminates the problem.
3. Check the Charging Circuit
A. Check the charging circuit. Refer to Special Instruction, REHS0354, "Charging System Troubleshooting".
Charging circuit
Result: The charging system is OK.
Proceed to Test Step 4.
Result: The charging system is not OK.
There is a problem with the charging system. Make the necessary repairs. Refer to Special Instruction, REHS0354, "Charging System Troubleshooting".
4. Load Test the Battery
A. Load test the battery. Refer to Systems Operation and Testing and Adjusting, "Battery - Test"
Load test
Result: The battery voltage is low or the battery did not pass the load test.
Recharge or replace the faulty batteries. Verify that the repair eliminates the problem.
Result: The batteries pass the load test. The measured voltage is between 11.5 VDC and 13.5 VDC for a 12 v system. The measured voltage is between 23.0 VDC and 27.0 VDC for a 24 v system.
Check the wiring between the batteries and the ECM / NOx sensor.
Check the connectors between the batteries and the ECM / NOx sensor for moisture and/or corrosion.
Repair or replace the wiring and/or the connectors.
Verify that the repair eliminates the problem.
Complete the procedure in the order in which the steps are listed.If the procedure corrected the issue, return the engine to service.If the procedure did not correct the issue, Contact your Cat dealer Technical Communicator (TC). For further assistance, your TC can confer with the Dealer Solutions Network (DSN).
