Table 1
Specifications for 360-1978 Bearing Kit
Callout     Part Number     Part Name     Specification Description
-     -     -     The original size of the main bearing journal is
83.980 to 84.000 mm (3.30629 to 3.30708 inch)
-     -     -     Maximum permissible wear of the main bearing journals is
0.040 mm (0.0016 inch)
-     -     -     Surface finish of bearing journals and crank pins is Ra 0.25 microns.
-     -     -     Width of new main bearing journal where the thrust washer is installed is
39.765 to 39.835 mm (1.56555 to 1.56830 inch)
-     -     -     Width of new main bearing journal where the thrust washer is not installed is
39.19 to 39.39 mm (1.54291 to 1.55078 inch)
-     -     -     First oversize bearing shell dimension is
0.25 mm (0.010 inch)
Second oversize bearing shell dimension is
0.50 mm (0.020 inch)
Third oversize bearing shell dimension is
0.50 mm (0.020 inch)
-     -     -     Thickness at center of the shells of oversize bearing shell
0.25 mm (0.010 inch) is
2.226 to 2.232 mm (0.08764 to 0.08787 inch)
-     -     -     Thickness at center of the shells of oversize bearing shell
0.50 mm (0.020 inch) is
2.353 to 2.359 mm (0.09264 to 0.09287 inch)
-     -     -     Thickness at center of the shells of oversize bearing shell
0.76 mm (0.030 inch) is
2.480 to 2.486 mm (0.09764 to 0.09787 inch)
-     -     -     Width of the main bearing shells is
26.32 to 26.58 mm (1.03622 to 1.04645 inch)
-     -     -     Clearance between the bearing shell and the main bearing journals is
0.036 to 0.094 mm (0.00142 to 0.00370 inch)    Removal Procedure
Table 2
Required Tools
Tool     Part Number     Part Description     Qty
A (1)     9U-6198     Crankshaft Turning Tool     1
( 1 ) Start By:
Remove the engine oil pump. Refer to Disassembly and Assembly, "Engine Oil Pump" for the correct procedure.
Remove the crankshaft rear seal. Refer to Disassembly and Assembly, "Crankshaft Rear Seal" for the correct procedure.
This procedure must only be used to remove and install the main bearing shells with the crankshaft in position.The removal procedure and the installation procedure must be completed for each pair of main bearing shells before the next pair of main bearing shells are removed.
Keep all parts clean from contaminants.Contaminants may cause rapid wear and shortened component life.
Ensure that the main bearing cap is marked for the correct location and orientation.
Illustration 1 g02204377
Remove bolts (3) from tube assembly (2) .
Remove tube assembly (2) from the cylinder block.
Remove gaskets (1) (not shown).
Illustration 2 g02204373
Remove bolts (4) and remove main bearing cap (5) from the cylinder block.
Illustration 3 g02204374
Remove lower main bearing shell (6) from main bearing cap (5). Keep the main bearing shell and the main bearing cap together.Note: The lower main bearing shell is a plain bearing that has no oil holes.
Illustration 4 g02204375
