Do not drain the oil when the engine is cold. As the oil cools, suspended waste particles settle on the bottom of the oil pan. The waste particles are not removed with the draining cold oil. Drain the crankcase with the engine stopped. Drain the crankcase with the oil warm. This draining method allows the waste particles that are suspended in the oil to be drained properly.Failure to follow this recommended procedure will cause the waste particles to be recirculated through the engine lubrication system with the new oil.Interval for Engine Oil and Engine Oil Filter Change
Note: The intervals stated in Table 1 are only valid when preferred lubricants are used. Using fluids other than the preferred fluids causes the engine to operate in a severe service application. Refer to this Operation and Maintenance Manual, "Fluid Recommendations" for information about which engine oils are preferred. Refer to this Operation and Maintenance Manual, "Severe Service Application" for information about the effect of using fluids which are not preferred on the maintenance intervals.
Table 1
Intervals for Changing the Engine Oil and Engine Oil Filter(1)
C9 Every 250 service hours or 1 yr
(1) Choose the interval that occurs first.Drain the Engine Oil
Care must be taken to ensure that fluids are contained during performance of inspection, maintenance, testing, adjusting, and repair of the product. Be prepared to collect the fluid with suitable containers before opening any compartment or disassembling any component containing fluids.Refer to Special Publication, NENG2500, "Cat Dealer Service Tool Catalog" or refer to Special Publication, PECJ0003, "Cat Shop Supplies and Tools Catalog" for tools and supplies suitable to collect and contain fluids on Cat products.Dispose of all fluids according to local regulations and mandates.
After the engine has been run at the normal operating temperature, stop the engine. Use one of the following methods to drain the engine crankcase oil:
If the engine is equipped with a drain valve, turn the drain valve knob counterclockwise in order to drain the oil. After the oil has drained, turn the drain valve knob clockwise in order to close the drain valve.
If the engine is not equipped with a drain valve, remove the oil drain plug in order to allow the oil to drain. If the engine is equipped with a shallow sump, remove the bottom oil drain plugs from both ends of the oil pan.After the oil has drained, the oil drain plugs should be cleaned and installed.Replace the Oil Filter
Caterpillar oil filters are built to Caterpillar specifications. Use of an oil filter not recommended by Caterpillar could result in severe engine damage to the engine bearings, crankshaft, etc., as a result of the larger waste particles from unfiltered oil entering the engine lubricating system. Only use oil filters recommended by Caterpillar.
Remove the oil filter with a 1U-8760 Chain Wrench.
Cut the oil filter open with a 175-7546 Oil Filter Cutter Gp. Break apart the pleats and inspect the oil filter for metal debris. An excessive amount of metal debris in the oil filter may indicate early wear or a pending failure.Use a magnet to differentiate between the ferrous metals and the nonferrous metals that are found in the oil filter element. Ferrous metals may indicate wear on the steel and cast iron parts of the engine.Nonferrous metals may indicate wear on the aluminum parts, brass parts, or bronze parts of the engine. Parts that may be affected include the following items: main bearings, rod bearings, turbocharger bearings and cylinder heads.Due to normal wear and friction, small amounts of debris may be found in the oil filter. Consult your Cat dealer in order to arrange for a further analysis if an excessive amount of debris is found in the oil filter.
Illustration 1 g00103713
Typical filter mounting base and filter gasket
Clean the sealing surface of the filter mounting base. Ensure that all of the old oil filter gasket is removed.
Apply clean engine oil to the new oil filter gasket.
Do not fill the oil filters with oil before installing them. This oil would not be filtered and could be contaminated. Contaminated oil can cause accelerated wear to engine components or engine damage.
Install the oil filter. Tighten the oil filter until the oil filter gasket contacts the base. Tighten the oil filter by hand according to the instructions that are shown on the oil filter. Do not overtighten the oil filter.Fill the Engine Crankcase
Remove the oil filler cap.
Refer to the Operation and Maintenance Manual, "Refill Capacities" for the amount of oil required to fill the crankcase. Fill the crankcase and replace the oil filler cap.
If equipped with an auxiliary oil filter system or a remote oil filter system, follow the OEM or filter manufacturer's recommendations. Under filling or overfilling the crankcase with oil can cause engine damage.
To prevent crankshaft bearing damage, crank the engine with the fuel OFF. This will fill the oil filters before starting the engine. Do not crank the engine for more than 30 seconds.
Start the engine and run the engine at "LOW IDLE" for 2 minutes. Perform this procedure in order to ensure that the lubrication system has oil and that the oil filters are filled. Inspect the oil filter for oil leaks.
Stop the engine and allow the oil to drain back to the sump for a minimum of 10 minutes.
Remove the oil level gauge in order to check the oil level. Maintain the oil level between the "ADD" and "FULL" marks on the oil level gauge.
