Table 1
J1939 Code and Description CDL Code and Description Comments
174-0
Engine Fuel Temperature 1 : High - most severe (3) E363 (3)
High Fuel Supply Temperature The fuel temperature sensor on the secondary filter head is higher than expected.
174-15
Engine Fuel Temperature 1 : High - least severe (1) E363 (1)
High Fuel Supply Temperature The fuel temperature sensor on the secondary filter head is higher than expected.
174-16
Engine Fuel Temperature 1 : High - moderate severity (2) E363 (2)
High Fuel Supply Temperature The fuel temperature sensor on the secondary filter head is higher than expected.
3468-0
Engine Fuel Temperature 2 : High - most severe (3) E770 (3)
High Fuel Rail Temperature The fuel temperature sensor on the high-pressure fuel pump is higher than expected.
3468-15
Engine Fuel Temperature 2 : High - least severe (1) E770 (1)
High Fuel Rail Temperature The fuel temperature sensor on the high-pressure fuel pump is higher than expected.
3468-16
Engine Fuel Temperature 2 : High - moderate severity (2) E770 (2)
High Fuel Rail Temperature The fuel temperature sensor on the high-pressure fuel pump is higher than expected.
Table 2
Associated Codes
J1939 Code CDL Code Troubleshooting Procedure
174-3 174-3 Troubleshooting, "Sensor Signal (Analog, Passive) - Test"
174-4 174-4 Troubleshooting, "Sensor Signal (Analog, Passive) - Test"
1077-11 1684-11 Troubleshooting, "Fuel Injection Pump Circuit - Test"
1077-12 1684-12 Troubleshooting, "Fuel Injection Pump Circuit - Test"
3468-3 2323-3 Troubleshooting, "Sensor Signal (Analog, Passive) - Test"
3468-4 2323-4 Troubleshooting, "Sensor Signal (Analog, Passive) - Test" If high fuel temperature shuts down the engine, cycle the power to the engine Electronic Control Module (ECM) to restart.
Table 3
Troubleshooting Test Step Value Result
1. Check for Diagnostic Codes
A. Apply electrical power to the engine.
B. Establish communication between Cat ® Electronic Technician (ET) to the service tool connector. Refer to Troubleshooting, "Electronic Service Tools", if necessary.
C. Look for active or logged diagnostic codes.
Diagnostic Codes
Result: An associated code is present.
Refer to the appropriate troubleshooting story.
Result: An E363, 174-0, 174-15, or 174-16 code is present.
Proceed to Test Step 2.
Result: An E770, 3468-0, 3468-15, 3468-16 code is present.
Proceed to Test Step 5.
2. Check the Fuel Tank Level
A. Remove electrical power from the engine.
B. Inspect the fuel level to make sure that the tank level is not too low.
Fuel Level
Result: The fuel level is OK.
Proceed to Test Step 3.
Result: The fuel level is NOT OK.
Proceed to Test Step 6.
3. Inspect the Fuel Cooler (If Equipped)
A. Remove electrical power from the engine.
B. Visually inspect the fuel cooler to see if there are any blockages or obstructions.
Blockages / Obstructions
Result: The fuel cooler is OK or the fuel cooler is not equipped.
Proceed to Test Step 4.
Result: The fuel cooler is NOT OK.
Repair: Remove the blockage or obstruction from the fuel cooler.
Proceed to Test Step 6.
4. Replace the Fuel Temperature Sensor
A. Remove electrical power from the engine.
B. Replace the fuel temperature sensor on the secondary filter head.
Fuel Temperature Sensor
Result: The fuel rail temperature sensor was replaced.
Proceed to Test Step 6.
5. Replace the Fuel Rail Temperature Sensor
A. Apply electrical power to the engine.
B. Establish communication between Caterpillar ® Electronic Technician (ET) to the service tool connector.
C. Wait for 10 minutes for the fuel rail pressure to drop below 5000 kPa (725 psi)(gauge).
Note: If the pressure is not less than 5000 kPa (725 psi) (gauge) after 10 minutes, vent the pressure from the fuel system. Refer to Systems Operation/Testing and Adjusting, Fuel Rail Pressure - Release for information.
D. Replace the fuel rail temperature sensor.
Fuel Rail Temperature Sensor
Result: The fuel rail temperature sensor was replaced.
Proceed to Test Step 6.
6. Check for Diagnostic Codes
A. Start the engine run to operating temperature.
B. Look for active or logged diagnostic codes.
Diagnostic Codes
Result: No codes present.
Return to service.
Result: An E770, 3468-0, 3468-15, 3468-16 code is active.
Repair: A failed high-pressure fuel pump has been detected.
Note: If the pressure is not less than 5000 kPa (725 psi) (gauge) after 10 minutes, vent the pressure from the fuel system. Refer to Systems Operation/Testing and Adjusting, Fuel Rail Pressure - Release for information.
Replace the high-pressure fuel pump.
If the procedure did not correct the issue, contact your Cat dealer Technical Communicator (TC). For further assistance, your TC can confer with the Dealer Solutions Network (DSN).
