2. Remove tubes (1) and (3).3. Disconnect hose (2). 4. Remove tube (7).5. Disconnect hose (6).6. Disconnect tube (5).7. Remove shield (4).8. Install a hoist on the air compressor. Remove the bolts that hold the air compressor to the engine. Remove the air compressor. Weight is 50 lb. (22.7 kg).Install Air Compressor
1. Use a hoist to put the air compressor in position on the engine. Install the bolts that hold it.2. Install the shield.3. Install the three tubes.4. Connect the two hoses.5. Connect the tube.6. Install coolant in the cooling system to the correct level. See the LUBRICATION AND MAINTENANCE GUIDE.Disassemble Air Compressor
start by:a) remove air compressor 1. Remove governor (1) from the air compressor. The governor can be removed from the air compressor while the air compressor is on the engine. 2. Remove caps (5). Remove springs (4) and valves (3).3. Remove head assembly (2). 4. Remove seats (6) from the head assembly. 5. Remove elbow (7) and screen (8) from the block. 6. Remove guides (10) and valves (12) from the block.7. Put the spring under compression. Remove the spring.8. Remove saddle (11) and pistons (9). Remove the rings and seals from the pistons.9. Remove the bushings and seats from the block only if worn or damaged. 10. Remove cover (13). 11. Remove connecting rod caps (14). 12. Remove the pistons from the block. 13. Remove rings (15) from piston (16). Remove bearings (19) from the rod and cap. Remove lock (20) from pin (18). Remove the pin and rod from the piston. Remove bushing (17) from the rod. Put identification on the pins, pistons, rods and caps for assembly. 14. Remove block (21) from the crankcase.15. Remove cover (22) from the crankcase. Remove the O-ring seal from the cover. Remove the bearing from the cover if worn or damaged. 16. Remove retainer (23).17. Use a press to remove the crankshaft from bearing (24). Remove the crankshaft from the crankcase. 18. Remove bearing (24) from the crankcase.Assemble Air Compressor
1. Crankshaft journals must not be more than 0.001 in. (0.03 mm) out of round. 2. Put the crankshaft in position in the crankcase. Use spacer (2), 1.75 in. (44.5 mm) outside diameter, 1.25 in. (31.8 mm) inside diameter and 4.5 in. (114.3 mm) long with a press to install bearing (1) on the crankshaft and in the crankcase. 3. Install retainer (3). Use a punch to move (peen) the retainer over the screws. 4. Use tooling (A) (if needed) to install bearing (5) in cover (4). Install the cover on the crankcase. 5. Install block (6) on the crankcase. Bores must not be more than 0.002 in. (0.05 mm) out of round or have more than a 0.003 in. (0.08 mm) taper. 6. Put the hole in bushing (9) in alignment with the hole in the rod. Use a press and tooling (B) to install the bushing. New bushings must be reamed or honed until there is a clearance of .0001 to .0006 in. (0.003 to 0.015 mm) between the bushing and the pin.7. Use pin (11) and lock (12) to install the rod in piston (8).8. Check the ring gap clearance with the ring in the cylinder. The clearance must be .005 to .015 in. (0.13 to 0.38mm).9. Use tool (C) to install the rings (7) on the piston (8).
There are wide and narrow rings. The rings must be installed with the bevel toward the top of the piston.
10. Check the groove clearance of the piston rings. The clearance for the wide rings must be .0035 to .0055 in. (0.089 to 0.140mm). The clearance for the narrow rings must be .002 to .004 in. (0.05 to 0.07 mm). 11. Install bearings (10) in the rods and caps. Put clean SAE 30 oil on the pistons and bearings. Use tool (D) to install the piston assemblies in the cylinders. 12. Check the clearance between the connecting rod bearing and crankshaft journals with Plastigage. Put Plastigage on bearing. Install the bearing caps (14) to the respective connecting rod. Tighten the bolts to a torque of 100 to 115 in. lb. (11.30 to 12.99 N m).13. Remove the bearing caps (14) and measure the Plastigage. The clearance must be between .0003 to .0021 in. (0.008 to 0.0533 mm).14. Put clean SAE 30 engine oil on the bearing caps and the bolts. Install the bearing caps, the bolts and the locks. Tighten the bolts to a torque of 100 to 115 in.lb. (11.30 to 12.99 N m). Bend the locks up against the bolts.15. Install the gasket and cover (13) on the crankcase.16. Install the bushings and seats in the block if they were removed.17. Install the rings and seals on the pistons. 18. Install pistons (17) and saddle (16) in the block. Install the spring.19. Install valves (18) and the guides in the block.20. Install the screen and elbow (15). 21. Install seats (20) in the head assembly.22. Install head assembly (19) on the block. 23. Install valves (21), springs (22) and caps (23) in the head assembly. 24. Install governor (24) on the air compressor.end by:a) install air compressor
