1660057 Volvo.Penta Pulley

Parameter Descriptions
"Product ID"
The "Product ID" parameter allows the customer to enter a description into the ECM in order to identify the machine. A maximum of 8 characters can be entered in the field."Equipment ID"
"Equipment ID" allows the customer to enter a description into the Electronic Control Module (ECM) in order to identify the machine. A maximum of 17 characters may be entered in the field. This parameter is only for reference by the customer. This parameter is not required."Engine Serial Number"
Program the "Engine Serial Number" to match the engine serial number that is stamped on the engine information plate. If the ECM is replaced, the engine serial number from the engine information plate must be programmed into the new ECM.Note: When you are requesting factory passwords, always use the engine serial number that is programmed in the ECM."FLS" (Full Load Setting)
"FLS" is a number that represents the adjustment to the fuel system that was made at the factory in order to fine tune the fuel system. The correct value for this parameter is stamped on the engine information plate. Factory passwords are required in order to change this parameter."FTS" (Full Torque Setting)
"FTS" is similar to "FLS". Factory passwords are required in order to change this parameter.System Configuration Parameters
Table 1
System Configuration Parameters
Parameter    Available Range or Options    Default    Required Password
ECM Identification Parameters
"Product ID"     8 alphanumeric character     "NOT PROGRAMMED"     None
"Equipment ID"     17 alphanumeric characters     "NOT PROGRAMMED"     None
"Engine Serial Number"     0XX00000 or XXX00000     0XX00000     None
"ECM Serial Number"     "Read Only" (1)
"ECM Part Number"     "Read Only" (1)
"Software Gp Part Number"     Software Dependent     Read Only (1)
"Software Gp Release Date"     Software Dependent     Read Only (1)
"FLS" (Full Load Setting)     - 128 to 127     0     Factory
"FTS" (Full Torque Setting)     -128 to 127     0     Factory
"Total Tattletale"     Read Only (1)
( 1 ) The parameter can only be viewed. No changes are allowed.
Parameters Worksheet
Note: A mistake in recording this information will result in incorrect passwords.
Table 2
Engine Parameters
ECM Identification Parameters
"Product ID"

"Equipment ID"

"Engine Serial Number"

"ECM Serial Number"

"Software Gp Part Number"

"Software Gp Release Date"

"FLS"

"FTS"

"Total Tattletale"

Information from Engine Information Plate
"Engine Serial Number"

"FLS"

"FTS"

Injector Codes
Injector Code (1)

Injector Code (2)

Injector Code (3)

Injector Code (4)

Injector Code (5)

Injector Code (6)
   Note: Compare the FLS and the FTS from the ECM with the values that are listed on the engine information plate. Only change the FLS and the FTS because of a mechanical change in the engine. The use of the wrong parameters could cause damage to the engine. The use of the wrong parameters may also void the Caterpillar warranty.Monitoring System
The monitoring system determines the level of action that is taken by the ECM in response to a condition that can damage the engine. The monitoring of the various sensors by the ECM can be turned "On" or "Off". These conditions are identified by the ECM from the signals that are produced from the following sensors:
Engine oil pressure sensor
Engine coolant temperature sensor
Engine speed/timing sensors
Intake manifold pressure sensor
Fuel pressure sensorThe monitoring system can be locked out. In order to change the settings, the monitoring system must be unlocked. Access the "Parameter Lockout" under the "Service" menu on the Caterpillar Electronic Technician (ET) in order to unlock the monitoring system.Warnings, derates, and shutdowns can be disabled for any parameter or for all of the parameters.
