833425 Volvo.Penta Pulley

Event Codes in J1939 Code Order
Table 1 is a list of the event codes for the engine. The event codes are listed in order of J1939 codes. The event codes are cross-referenced with the appropriate procedure that can be used to troubleshoot the code.
Table 1
Event Codes
J1939 Code and Description CDL Code and Description Troubleshooting Procedure
97-15
Water In Fuel Indicator : High - least severe (1) E232 (1)
High Fuel/Water Separator Water Level Troubleshooting, "Fuel Contains Water"
97-16
Water In Fuel Indicator : High - moderate severity (2) E232 (2)
High Fuel/Water Separator Water Level Troubleshooting, "Fuel Contains Water"
100-1
Engine Oil Pressure : Low - most severe (3) E360 (3)
Low Engine Oil Pressure Troubleshooting, "Oil Pressure Is Low"
100-17
Engine Oil Pressure : Low - least severe (1) E360 (1)
Low Engine Oil Pressure Troubleshooting, "Oil Pressure Is Low"
100-18
Engine Oil Pressure : Low - moderate severity (2) E360 (2)
Low Engine Oil Pressure Troubleshooting, "Oil Pressure Is Low"
102-16
Engine Intake Manifold #1 Pressure : High - moderate severity (2) E1044 (2)
High Intake Manifold Pressure Troubleshooting, "Intake Manifold Air Pressure Is High"
102-18
Engine Intake Manifold #1 Pressure : Low - moderate severity (2) E1045 (2)
Low Intake Manifold Pressure Troubleshooting, "Intake Manifold Air Pressure Is Low"
105-0
Engine Intake Manifold #1 Temperature : High - most severe (3) E539 (3)
High Intake Manifold Air Temperature Troubleshooting, "Intake Manifold Air Temperature Is High"
105-15
Engine Intake Manifold #1 Temperature : High - least severe (1) E539 (1)
High Intake Manifold Air Temperature Troubleshooting, "Intake Manifold Air Temperature Is High"
105-16
Engine Intake Manifold #1 Temperature : High - moderate severity (2) E539 (2)
High Intake Manifold Air Temperature Troubleshooting, "Intake Manifold Air Temperature Is High"
107-15
Engine Air Filter 1 Differential Pressure : High - least severe (1) E583 (1)
High Engine Air Filter #1 Differential Pressure Troubleshooting, "Inlet Air Is Restricted"
107-16
Engine Air Filter 1 Differential Pressure : High - moderate severity (2) E583 (2)
High Engine Air Filter #1 Differential Pressure Troubleshooting, "Inlet Air Is Restricted"
110-0
Engine Coolant Temperature : High - most severe (3) E361 (3)
High Engine Coolant Temperature Troubleshooting, "Coolant Temperature Is High"
110-15
Engine Coolant Temperature : High - least severe (1) E361 (1)
High Engine Coolant Temperature Troubleshooting, "Coolant Temperature Is High"
110-16
Engine Coolant Temperature : High - moderate severity (2) E361 (2)
High Engine Coolant Temperature Troubleshooting, "Coolant Temperature Is High"
111-1
Engine Coolant Level : Low - most severe (3) E2143 (3)
Low Engine Coolant Level Troubleshooting, "Coolant Level Is Low"
111-18
Engine Coolant Level : Low - moderate severity (2) E2143 (2)
Low Engine Coolant Level Troubleshooting, "Coolant Level Is Low"
157-16
Engine Injector Metering Rail #1 Pressure : High - moderate severity (2) E396 (2)
High Fuel Rail Pressure Troubleshooting, "Fuel Rail Pressure Problem"
157-18
Engine Injector Metering Rail #1 Pressure : Low - moderate severity (2) E398 (2)
Low Fuel Rail Pressure Troubleshooting, "Fuel Rail Pressure Problem"
168-31
Battery Potential / Power Input #1 E441 (1)
Idle Elevated to Increase Battery Voltage Troubleshooting, "Battery Problem"
190-0
Engine Speed : High - most severe (3) E362 (3)
Engine Overspeed Troubleshooting, "Engine Overspeeds"
190-15
Engine Speed : High - least severe (1) E362 (1)
Engine Overspeed Troubleshooting, "Engine Overspeeds"
593-31
Engine Idle Shutdown has Shutdown Engine E1171 (1)
Engine Idle Shutdown Occurred This code indicates that an engine idle shutdown has occurred.
This code does not represent a fault.
594-31
Engine Idle Shutdown Driver Alert Mode E1172 (3)
Engine Idle Shutdown Pending This code indicates that an engine idle shutdown is about to occur.
This code does not represent a fault.
970–31
Engine Auxiliary Engine Shutdown Switch E264 (3)
Emergency Stop Activated This event code will be set when the remote emergency stop switch is activated. This event will prevent engine operation.
1109-31
Engine Protection System Approaching Shutdown E1377 (1)
Machine Disable Pending Due to Machine Security This code indicates that the machine security system does not recognize the ignition key. Ensure that the correct key is in use.
1110-31
Engine Protection System has Shutdown Engine E1377 (2)
Machine Disable Pending Due to Machine Security This code indicates that the machine security system does not recognize the ignition key. Ensure that the correct key is in use.
1382-15
Engine Fuel Filter (suction side) Differential Pressure : High - least severe (1) E390 (1)
Fuel Filter Restriction Troubleshooting, "Fuel Filter Is Restricted"
1382-16
Engine Fuel Filter (suction side) Differential Pressure : High - moderate severity (2) E390 (2)
Fuel Filter Restriction Troubleshooting, "Fuel Filter Is Restricted"
1664-31
Engine Automatic Start Failed E225 (2)
Engine Overcrank Troubleshooting, "Engine Overcrank Occurrence"
5580-0
Engine Filtered Fuel Delivery Absolute Pressure : High - most severe (3) E198 (2)
Low Fuel Pressure Troubleshooting, "Fuel Pressure Is Low"
5580-17
Engine Filtered Fuel Delivery Absolute Pressure : Low - least severe (1) E198 (3)
Low Fuel Pressure Troubleshooting, "Fuel Pressure Is Low"
5580-18
Engine Filtered Fuel Delivery Absolute Pressure : Low - moderate severity (2) E198 (1)
Low Fuel Pressure Troubleshooting, "Fuel Pressure Is Low" Event Codes in Cat Data Link (CDL) Code Order
Table 2 is a list of the event codes for the engine. The event codes are listed in order of CDL codes. The event codes are cross-referenced with the appropriate procedure that can be used to troubleshoot the code.
Table 2
Event Codes
