6210773 Volvo.Penta Screw


6210773 Screw Volvo.Penta 2001; 2001B; 2001AG, AD30A; AQAD30A; MD30A, AD31D; AD31D-A; AD31XD, AD31L-A; AD31P-A; AD41L-A, AD41D; D41D; TAMD41D, MD31A; TMD31A; TMD31B, MD31A; TMD31B; TAMD31B, MD40A; TMD40A; TMD40B, TD30A; TD31ACE; TD40A, TD60D; TD60D-83; TD60DPP-83, TD70G; TD70 Screw
6210773 Screw Volvo Penta
Rating:
58

Buy Screw 6210773 Volvo Penta genuine, new aftermarket parts with delivery
Number on catalog scheme: 5


Volvo Penta entire parts catalog list:

2001; 2001B; 2001AG; 2001BG; 2002; 2002B; 2002D; 2002AG; 2002BG; 2003; 2003B; 2003D; 2003AG; 2003BG; 2003T; 2003TB; 2003 SOLAS; 2003B SOLAS; 2003T
AD30A; AQAD30A; MD30A; TAMD30A; TMD30A; AD30; AQAD30; MD30; TAMD30; TMD30
AD31D; AD31D-A; AD31XD; TAMD31D; TMD31D
AD31L-A; AD31P-A; AD41L-A; AD41P-A; D41L-A; TAMD31L-A; TAMD31M-A; TAMD31P-A; TAMD31S-A; TAMD41H-A; TAMD41H-B; TAMD41P-A; TAMD41L-A; TAMD41M-A
AD41D; D41D; TAMD41D; TMD41D; HS1A
MD31A; TMD31A; TMD31B; TAMD31A; TAMD31B; AD31; AQAD31A; AD31B; 290A; DP-A; DP-B; DP-A1; DP-B1; SP-A; SP-A1
MD31A; TMD31B; TAMD31B; AD31B
MD40A; TMD40A; TMD40B; TMD40C; AQD40A; TAMD40A; TAMD40B; AD40B; AQAD40A; AQAD40B
TD30A; TD31ACE; TD40A; TD45B; D45A
TD60D; TD60D-83; TD60DPP-83; TD60DG-83; TID60D; TID60DG
TD70G; TD70G-83; TD70GPP; TD70GPP-83; TID70G; TID70GPP; TID70GG; TD70GG; TD70GG-83
TMD41A; TMD41B; D41A; D41B; TAMD41A; TAMD41B; AQAD41A; AD41A; AD41B; 290A; DP-A; DP-B; DP-A1; DP-B1; SP-A; SP-A1; AD41BJ; AD41; AD41P-B; D41; TAMD41
TMD41B; D41B; TAMD41B; AD41B; AD41BJ

Information:

Engine Design
Cylinder And Valve IdentificationBore ... 120.7 mm (4.75 in)Stroke ... 152.4 mm (6.00 in)Number of Cylinders ... 6Cylinder Arrangement ... in-lineFiring Order (Injection Sequence) ... 1,5,3,6,2,4Direction of Rotation (when seen from flywheel end) ... CounterclockwiseThe No. 1 Cylinder Is Opposite Flywheel End.Fuel System
Fuel Flow
Fuel System Schematic
(1) Fuel tank. (2) Fuel return line. (3) Priming pump. (4) Fuel injection nozzle. (5) Fuel injection line. (6) Fuel injection pump. (7) Primary fuel filter. (8) Check valve. (9) Fuel transfer pump. (10) Secondary fuel filter. (11) Constant bleed orifice. (12) Fuel injection pump housing.Fuel is pulled from fuel tank (1) through primary fuel filter (7) and check valves (8) by fuel transfer pump (9). From the fuel transfer pump the fuel is pushed through secondary fuel filter (10) and to the fuel manifold in fuel injection pump housing (12). The pumping spring in the fuel transfer pump keeps the fuel pressure in the system at 170 to 290 kPa (25 to 42 psi). Constant bleed orifice (11) lets a constant flow of fuel go through fuel return line (2) back to fuel tank (1). This helps keep the fuel cool and free of air. Fuel injection pump (6) gets fuel from the fuel manifold and pushes fuel at very high pressure through fuel line (5) to fuel injection nozzle (4). The fuel injection nozzle has very small holes in the tip that change the flow of fuel to a very fine spray that gives good fuel combustion in the cylinder.Fuel Injection Pump
The fuel injection pump increases the pressure of the fuel and sends an exact amount of fuel to the fuel injection nozzle. There is one fuel injection pump for each cylinder in the engine.The fuel injection pump is moved by cam (12) of the fuel pump camshaft. When the camshaft turns, the cam raises lifter (11) and pump plunger (7) to the top of the stroke. The pump plunger always makes a full stroke. As the camshaft turns farther, spring (8) returns the pump plunger and lifter to the bottom of the stoke.When the pump plunger is at the bottom of the stroke, fuel transfer pump pressure goes into inlet passage (1), around the pump barrel and to bypass closed port (3). Fuel fills the area above the pump plunger.After the pump plunger begins the up stroke, fuel will be pushed out the bypass closed port until the top of the pump plunger closes the port. As the pump plunger travels farther up, the pressure of the fuel increases. At approximately 690 kPa (100 psi), check valve (2) opens and lets fuel flow into the fuel injection line to the fuel injection nozzle. When the pump plunger travels farther up, scroll (5) uncovers spill port (4). The fuel above the pump plunger goes through slot (6), along the edge of scroll (5) and out spill port (4) back to the fuel manifold. This is the end of the injection stroke. The pump plunger can have more travel up, but no more fuel will be sent to the fuel injection nozzle.
Fuel Injection Pump
(1) Inlet passage. (2) Check valve. (3) Bypass closed port. (4) Spill port. (5) Scroll. (6) Slot. (7) Pump plunger. (8) Spring. (9) Fuel rack. (10) Gear. (11) Lifter. (12) Cam.When the pump plunger travels down and uncovers bypass closed port (3), fuel begins to fill the area above the pump plunger again, and the pump is ready to begin another stroke.The amount of fuel the injection pump sends to the injection nozzle is changed by the rotation of the pump plunger. Gear (10) is attached to the pump plunger and is in mesh with fuel rack (9). The governor moves the fuel rack according to the fuel needs of the engine. When the governor moves the fuel rack, and the fuel rack turns the pump plunger, scroll (5) changes the distance the pump plunger pushes fuel between bypass closed port (3) and spill port (4) opening. The longer the distance from the top of the pump plunger to the point where scroll (5) uncovers spill port (4), the more fuel will be injected.To stop the engine, the pump plunger is rotated so that slot (6) on the pump plunger is in line with spill port (4). The fuel will now go out the spill port and not to the injection nozzle.Fuel Injection Nozzle
The fuel injection nozzle goes through the cylinder head into the combustion chamber. The fuel injection pump sends fuel with high pressure to the fuel injection nozzle where the fuel is made into a fine spray for good combustion.
Fuel Injection Nozzle
(1) Carbon dam. (2) Seal. (3) Passage. (4) Filter screen. (5) Orifice. (6) Valve. (7) Diameter. (8) Spring.Seal (2) goes against the cylinder head and prevents leakage of compression from the cylinder. Carbon dam (1) keeps carbon out of the bore in the cylinder head for the nozzle.Fuel with high pressure from the fuel injection pump goes into the inlet passage. Fuel then goes through filter screen (4) and into passage (3) to the area below diameter (7) of valve (6). When the pressure of the fuel that pushes against diameter (7) becomes greater than the force of spring (8), valve (6) lifts up. This occurs when the fuel pressure goes above the Valve Opening Pressure of the fuel injection nozzle. When valve (6) lifts, the tip of the valve comes off the nozzle seat and the fuel will go through orifices (5) into the combustion chamber.The injection of fuel continues until the pressure of fuel against diameter (7) becomes less than the force of spring (8). With less pressure against diameter (7), spring (8) pushes valve (6) against the nozzle seat and stops the flow of fuel to the combustion chamber.The fuel injection nozzle can not be disassembled and no adjustments can be made.Fuel Transfer Pumps
7N6831
Fuel Transfer Pump Schematic (up stroke)
(1) Bypass valve. (2) Pumping spring. (3) Small piston. (4) Outlet. (5) Inlet check valve. (6) Push plate. (7) Pumping check valve. (8)
