Table 1
Diagnostic Codes Table
Code and Description Conditions which Generate this Code System Response
41-3 8 Volt DC Supply voltage above normal The digital sensor supply voltage is above normal for one second.
The Electronic Control Module (ECM) has been powered for three seconds. The code is logged.
All sensors are set to default values.
41-4 8 Volt DC Supply voltage below normal The digital sensor supply voltage is below normal for one second.
The ECM has been powered for three seconds.
262-3 5 Volt Sensor DC Power Supply voltage above normal The analog sensor supply voltage is above normal for one second.
The ECM has been powered for three seconds. The code is logged.
All sensors are set to default values.
262-4 5 Volt Sensor DC Power Supply voltage below normal The analog sensor supply voltage is below normal for one second.
The ECM has been powered for three seconds.
269-3 Sensor Power Supply voltage above normal The analog sensor supply voltage is above normal for one second.
The ECM has been powered for three seconds. The code is logged.
All sensors are set to default values.
269-4 Sensor Power Supply voltage below normal The analog sensor supply voltage is below normal for one second.
The ECM has been powered for three seconds.
1785-10 Intake Manifold Pressure Sensor abnormal rate of change The ECM detects a value for the intake manifold pressure that is between 191 kPa (28 psi) and 252 kPa (37 psi). The pressure changes less than 0.55 kPa (0.08 psi) in 30 seconds.
The engine speed must be greater than 1000 rpm in order for this code to be set. The code is logged.
The value of the parameter will be set to 100 kPa (15 psi). Note: The 262 diagnostic codes indicate a problem with the 5 V power supply on the J2 ECM connector. The 269 diagnostic codes indicate a problem with the 5 V power supply on the J1 ECM connector.System OperationThe ECM supplies a regulated voltage of 5.0 0.2 VDC to the following sensors:
Fuel pressure sensor
Engine oil pressure sensor
Injection actuation pressure sensor
Atmospheric pressure sensor
Turbocharger inlet pressure sensor
Intake manifold pressure sensorThe ECM supplies a regulated voltage of 8.0 0.4 VDC to the throttle position sensor.The supply voltage for the sensors is routed from the ECM to terminal A of each sensor connector. The sensor return for the sensors is routed from the ECM to terminal B of each sensor connector. The ECM provides short circuit protection for the internal power supply. A short circuit to the battery will not damage the internal power supply.If a -10 code is logged, this indicates that the 5 volt supply is not available at the sensor connector. During normal engine operation, each of the signals from the pressure sensors fluctuate slightly. When the 5 volt supply becomes unavailable at the pressure sensor connector, the signal from that sensor floats to a midrange value. The signal will not fluctuate. If the signal from the sensor remains abnormally steady for more than 30 seconds, the ECM will activate this code.Note: The sensors are not protected from overvoltage. A short from the supply line to the +Battery may damage the sensors. If any of the 3 diagnostic codes are active, it is possible that a sensor has been damaged. Repair the sensor supply and check for any active sensor diagnostic codes in order to determine if a sensor has failed.
Illustration 1 g01339831
Schematic for the sensor supply circuit
Test Step 1. INSPECT THE ELECTRICAL CONNECTORS AND THE WIRING
Remove electrical power from the ECM.
Illustration 2 g01339949
Locations of the components that are associated with the sensor supply circuits
Component locations for the analog sensors (typical left side engine view)
(1) Intake manifold pressure sensor
(2) Atmospheric pressure sensor
(3) Turbocharger inlet pressure sensor
(4) Fuel pressure sensor
(5) Injection actuation pressure sensor
(6) Engine oil pressure sensor
(7) J2/P2 ECM connector
(8) J1/P1 ECM connector
(9) Machine interface connector (20-Pin)
Thoroughly inspect the connectors for sensors (1 through 6). Also, thoroughly inspect connectors (7), (8), and (9). Refer to Troubleshooting, "Electrical Connectors - Inspect" for details.
Illustration 3 g01340124
Terminal locations at the P1 ECM connector for the sensor supply
(P1-2) 5 V Sensor supply
(P1-3) Sensor return
(P1-4) 8 V Sensor supply
(P1-5) Sensor return
Illustration 4 g01340136
Terminal locations at the P2 ECM connector for the sensor supply
(P2-17) Sensor return
(P2-54) Sensor return
(P2-72) 5 V Sensor supply
(P2-80) 5 V Sensor supply
Illustration 5 g01339654
Terminal locations at the machine interface connector for the sensor supply
(Terminal 9) 8 V sensor supply
(Terminal 12) Sensor return
Illustration 6 g01159881
Terminal locations at the sensor connector for the sensor supply
(Terminal A) 5 V or 8 V sensor supply
(Terminal B) Sensor return
(Terminal C) Sensor signal
Perform a 45 N (10 lb) pull test on each of the wires in the ECM connectors that are associated with the circuit.
Check the allen head screw for each of the ECM connectors for the proper torque. Refer to Troubleshooting, "Electrical Connectors - Inspect" for details.
Check the harness and wiring for abrasion and for pinch points from the sensors back to the ECM. Expected Result:All connectors, pins and sockets are completely coupled and/or inserted and the harness and wiring are free of corrosion, of abrasion and of pinch points.Results:
OK - The harness and connectors appear to be OK. Proceed to Test Step 2.
Not OK -
