21951469 Volvo.Penta Shaft kit

Parameter Descriptions
"Product ID"
The "Product ID" parameter allows the customer to enter a description into the ECM in order to identify the machine. A maximum of 8 characters can be entered in the field."Equipment ID"
"Equipment ID" allows the customer to enter a description into the Electronic Control Module (ECM) in order to identify the machine. A maximum of 17 characters may be entered in the field. This parameter is only for reference by the customer. This parameter is not required."Engine Serial Number"
Program the "Engine Serial Number" to match the engine serial number that is stamped on the engine information plate. If the ECM is replaced, the engine serial number from the engine information plate must be programmed into the new ECM.Note: When you are requesting factory passwords, always use the engine serial number that is programmed in the ECM."FLS" (Full Load Setting)
"FLS" is a number that represents the adjustment to the fuel system that was made at the factory in order to fine tune the fuel system. The correct value for this parameter is stamped on the engine information plate. Factory passwords are required in order to change this parameter."FTS" (Full Torque Setting)
"FTS" is similar to "FLS". Factory passwords are required in order to change this parameter."Ether Control"
The "Ether Control" parameter allows the operation of this feature to be enabled or disabled."Security System Immobilizer"
The "Engine Security System Status" will inform the user if the system has been installed and if the system has been enabled. If the ECM does not detect the security system, the status will be "Unavailable". Once the ECM detects the security system on the data link, the parameter is changed to "Enabled". The user can disable this parameter with factory passwords.System Configuration Parameters
Table 1
System Configuration Parameters
Parameter Available Range or Options Default Required Password
ECM Identification Parameters
"Product ID" 8 alphanumeric character "NOT PROGRAMMED" None
"Equipment ID" 17 alphanumeric characters "NOT PROGRAMMED" None
"Engine Serial Number" 0XX00000 or XXX00000 0XX00000 None
"ECM Serial Number" "Read Only" (1)
"ECM Part Number" "Read Only" (2)
"Software Gp Part Number" Software Dependent Read Only (1)
"Software Gp Release Date" Software Dependent Read Only (1)
"Software Gp Release Date" Software Dependent Read Only (1)
"FLS" (Full Load Setting) - 128 to 127 0 Factory
"FTS" (Full Torque Setting) -128 to 127 0 Factory
"Ether Control" "Enable" or "Disable" "Disable" None
"Security System Immobilizer" "Enable" or "Disable" "Enabled" Factory
"Total Tattletale" Read Only (1)
(1) The parameter can only be viewed. No changes are allowed.
(2) The parameter can only be viewed. No changes are allowed.Parameters Worksheet
Note: A mistake in recording this information will result in incorrect passwords.
Table 2
Engine Parameters
ECM Identification Parameters
"Product ID"
"Equipment ID"
"Engine Serial Number"
"ECM Serial Number"
"Software Gp Part Number"
"Software Gp Release Date"
"FLS"
"FTS"
"Ether Control"
"Security System Immobilizer"
"Total Tattletale"
Injector Codes
Injector Code (1)
Injector Code (2)
Injector Code (3)
Injector Code (4)
Injector Code (5)
Injector Code (6)
Note: Compare the FLS and the FTS from the ECM with the values that are listed on the engine information plate. Only change the FLS and the FTS because of a mechanical change in the engine. The use of the wrong parameters could cause damage to the engine. The use of the wrong parameters may also void the Caterpillar warranty.
