3. Remove bolts (4) and remove fuel transfer pump (3). Install Fuel Transfer Pump
1. Install O-ring seal (2) on fuel transfer pump (1). 2. Put a light layer of clean engine oil in the bore for O-ring seal (2).3. Put the gasket and fuel transfer pump (1) in position.4. Install the bolts that hold the fuel transfer pump (1) to the engine. 5. Connect fuel lines (3) and (4) to the fuel transfer pump.6. Turn the fuel supply valve on the bottom of the fuel tank to the "ON" position and remove (bleed) the air from the fuel system.Disassemble Fuel Transfer Pump
start by:a) remove fuel transfer pump1. Remove cover (3) from transfer pump cover (4). 2. Remove bolts (1). Make a separation between cover (4) and pump body (2).3. Remove lip type seal (6) from the cover. Remove plug (5), seal, spring and plunger (bypass valve) from the cover. 4. Remove nut (10) from shaft (7). Remove gear (9) and key (11). 5. Remove shaft (7) and gear (8) as a unit. Remove gear (8) from drive shaft (7) with a press.6. Remove idler gear (12). 7. Remove bushing (14), two lip type seals and the bottom bearing from pump body (2).8. Remove check valve (13).Assemble Fuel Transfer Pump
1. Install bushing (4) in body (3) with tooling (B). The bushing must not be extended above the (gear) surface of the body.2. Install the check valve in the body with tooling (A).3. Install lip type seal (5) with tooling (C). Install the seal until it is 24.6 0.5 mm (.97 .02 in.) from the bottom surface of body (3) and with the lip toward bushing (4) as shown. 4. Install lip type seal (6) with tooling (D). Install the seal until it is 14.2 0.5 mm (.56 .02 in.) from the bottom surface of body (3) and with the lip away from seal (5) as shown.5. Install bearing (7) in body (3) with tooling (E). The bearing must be even with the surface of the pump body.6. Heat gear (8) to a maximum temperature of 316°C (600°F). Install gear (8) on shaft (11) until dimension (X) is 49.71 0.25 mm (1.957 0.10 in.). 7. Install the drive shaft and gear in body (3). Install key, gear (10) and nut (9). Tighten the nut to a torque of 28 7 N m (22 5 lb.ft.).8. Install idler gear (12) in body (3).9. Install lip type seal (2) with tooling (C). Install the seal until it is 3.8 0.5 mm (.15 .02 in.) from the top surface of cover (1) with the lip toward the inside as shown.10. Install plunger (14) (bypass valve), spring (15), seal plug (13) in pump cover (1). Tighten plug (13) to a torque of 28 4 N m (27 3 lb.ft.). 11. Put 7M7260 Liquid Gasket Material on the surface of cover (1). Install cover (1) on pump body (3).
Do not let the liquid gasket enter the pump.
The drive shaft must turn freely after the bolts that hold the transfer pump together are tightened.12. Install the cover on cover (1).end by:a) install fuel transfer pump
