Introduction
This Special Instruction is intended to provide information on the Engine Rebuild Kit Consist and detailed information on specific parts that should be used based on engine arrangements.This Engine Rebuild Kit may contain extra parts and extra quantities due to the variety of engine arrangements assigned to a given kit. Refer to the corresponding Parts Manual or Disassembly and Assembly manual in Table 1.Note: This Kit may contain upgraded parts. These upgraded part numbers may be different than what you have in the parts manual or engine, but these parts have been technically reviewed for compatibility with your application. Note: This kit contains gasket kits and includes additional parts needed to perform an engine rebuild.Note: This kit contains a set of six standard rod bearings.Note: This kit does not contain main bearings and thrust plates.Note: For more information, visit us at: www.parts.cat.com/rebuildkits.Note: For assistance with technical questions, contact your local Cat dealer. Reference Material
Table 1
Engine Model     Machine Model     Machine Serial Number Prefix     Engine Arrangement     Engine Serial Number Prefix     Parts Book Media     Disassembly and Assembly Media
C15 ACERT     583T     S/N:CMX     296-6027     S/N:LHX
S/N:TXG     SEBP4415     RENR8261
189-2620
D8T S/N:J8B
S/N:KPZ     225-0097     S/N:LHX
S/N:TXG     SEBP4195
237-9123
PL83 S/N:KSD     189-2620     S/N:LHX
S/N:TXG     SEBP5810    Note: For ordering reference material contact your local Cat dealer.C15 ACERT 446-7654 Engine Rebuild Kit Consist
Table 2
446-7654 Engine Rebuild Kit Consist
Gasket Kits
Part Number     Part Name     Qty
443-7406     Front Structure Gasket Kit     1
443-7411     Rear Structure Kit     1
443-7407     Single Cylinder Head Gasket Kit     1
443-7405     Central and Lower Structure Gasket Kit     1
443-7409     Oil Cooler and Lines Gasket Kit     1
Additional Parts Included in This Kit
Part Number     Part Name     Qty
1R-0762     Fuel Filter     1
1R-1808     Engine Oil Filter     1
2J-3118     Locking Bolt     5
2N-2766     Locknut     12
4N-4668     Breather As     1
4N-8150     Spring     2
5P-4255     Locking Bolt     8
6V-5063     O-Ring Seal     3
6V-6923     Backup Ring     1
8S-9191     Bolt     6
101-8468     Bushing     1
106-1792     Taperlock Stud     12
125-0434     Integral Seal     1
130-4698     Bushing     1
131-7123     Bushing     1
171-4358     O-Ring Seal     2
209-8622     Bushing     2
209-8624     Bushing     2
224-3246     Connecting Rod Bearing     6
248-5513     Temperature Regulator     2
297-1813     Head Screw     12
392-9208     Valve Plunger     2    Note: For assistance or technical questions contact your local Cat dealer.Note: Refer to Illustration 1 for location of gasket kits.C15 ACERT Engine Gasket Kit Locations
Illustration 1 g03521160
(1) Single Cylinder Head ( 443-7407 Gasket Kit ) (2) Front Structure ( 443-7406 Gasket Kit ) (3) Central and Lower Structure ( 443-7405 Gasket Kit ) (4) Oil Cooler and Lines ( 443-7409 Gasket Kit ) (5) Rear Structure ( 443-7411 Gasket Kit )Gasket Kit Consists
Front Structure (443-7406 Gasket Kit)
Table 3
443-7406 Gasket Kit (Front Structure)
Part Number &nbs
